Eaton E2ME38002WS29 Mining MCCB - UL Listed
Part Number: E2ME38002WS29
Quick Summary
Eaton E2ME38002WS29 is a mining MCCB that provides reliable overcurrent protection for three‑phase electrical feeders. Operators in harsh mining environments face unplanned trips, downtime, and compliance risks that erode productivity. This unit carries UL Listed and CSA Certified ratings, ensuring safety and regulatory alignment for critical mining applications. Designed to fit standard enclosures while delivering rugged performance, it supports remote shutdown with a 110–127 V shunt trip and helps lower total cost of ownership. For procurement teams, its clear specification, rugged build, and industry alignment translate to faster approvals, predictable maintenance costs, and reliable uptime.
Product Information
Extended Description
E2ME38002WS29 Eaton: 3 POLE 800 AMP 600 V LSI MINING CIRCUIT BREAKER 1000-4000 TRIP RANGE WITH 110-127 VAC SHUNT TRIP
Product Name
Eaton E2 mining complete molded case circuit breaker
Catalog Number
E2ME38002WS29
UPC
786689663339
Product Length/Depth
19 in
Product Height
9 in
Product Width
11 in
Product Weight
32 lb
Certifications
UL Listed CSA Certified
Type
Specialty complete
Class
Mining
Robinson Mine Case Study: Solutions for the mining industry
Eaton Specification Sheet - E2ME38002WS29
Feature: Three-pole design provides comprehensive three-phase protection. Business Impact: Reduces risk of phase-to-phase faults and equipment damage, improving uptime for mining conveyors and crushers. Application: Use in main feeders and distribution panels in underground or open-pit operations. Feature: 800 A current rating at 600 V enables handling high inrush and sustained loads. Business Impact: Supports heavy mining loads with minimal nuisance trips, reducing unnecessary downtime. Application: Protection for large motor drives and feeders in mineral processing. Feature: Trip range 1000–4000 A with shunt trip capability. Business Impact: Flexible protection settings and remote isolation for safety-critical shutdowns during maintenance or emergency events. Application: Underground mining installations requiring rapid, verifiable trips. Feature: 110–127 VAC shunt trip. Business Impact: Enables remote or automated safety interlock integration, enhancing plant-wide safety protocols. Application: Integration with control systems and emergency shutdown networks. Feature: Compact 19 in L, 11 in W, 9 in H footprint with 32 lb weight. Business Impact: Easy mounting in standard MCCB enclosures, saving panel space and simplifying retrofits. Application: Upgrades or replacements in existing mining panels. Feature: UL Listed and CSA Certified. Business Impact: Compliance-ready equipment that mitigates regulatory risk and supports audit readiness. Application: Requirement for safety certifications in North American mining facilities.
Get a Quick Quote for a Eaton E2ME38002WS29
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton E2ME38002WS29?
Enquire Now
FAQs
Eaton E2ME38002WS29 is designed for standard 19 inch MCCB enclosures common in mining panels. Ensure three‑pole mounting space, adequate clearance for the 32 lb unit, and compatibility with 600 V systems. Plan for the 110–127 VAC shunt trip wiring and maintain proper torque on terminal connections to sustain reliable operation in harsh environments.
Key specs include a 3-pole design, 800 A current rating, 600 V voltage rating, and a trip range of 1000–4000 A. It also features a 110–127 VAC shunt trip for remote isolation and weighs 32 lb with dimensions of 19 in length, 9 in height, and 11 in width. These details support large mining motor protection while fitting standard panels.
Yes. It is a mining‑class MCCB with a mining designation and UL Listed, CSA Certified ratings, intended for rugged environments. Its 3‑pole configuration, high current capacity, and remote trip capability make it suitable for conveyors, crushers, and other three‑phase mining electrical feeders requiring reliable protection and quick isolation.
The device carries UL Listed and CSA Certified markings, which ensures compliance with major safety standards in North America. These certifications support regulatory alignment for mining equipment, simplify audit processes, and help ensure safe operation within industrial control panels and distribution systems.
The E2ME38002WS29 offers rugged construction, reliable trip performance, and certified safety, contributing to reduced unplanned downtime and streamlined maintenance planning. Its compatibility with standard enclosures minimizes retrofit costs, while remote trip capability supports faster response during emergencies, potentially lowering overall maintenance expenses and improving asset uptime.
