Eaton Arc Flash Relay EAFR-101C-B - UL Recognized
Part Number: EAFR-101C-B
Quick Summary
Eaton Arc Flash Relay EAFR-101C-B provides fast fault sensing for electrical protection in industrial switchgear. End users struggle with nuisance trips and unreliable protection caused by sensor misconfigurations and delayed signaling. UL Recognized and cUL Recognized listings help ensure global safety compliance, supporting reliable arc flash protection across regions. Designed as a 12 point sensor unit with 4 trip relays, it scales protection programs while delivering cost-effective maintenance. This solution integrates seamlessly into existing protection schemes, enabling robust arc flash protection while reducing downtime and operational risk.
Product Information
Extended Description
EAFR-101C-B Eaton: Arc Flash Relay, 18-72 Vac/dc, 12 Point Sensor Inputs, 4 Trip Relays, 50/60 Hz, 12 Max point sensors, 4 trip relays, Point sensor unit
Product Name
Eaton arc flash relay point sensor
Catalog Number
EAFR-101C-B
UPC
786679186114
Product Length/Depth
6.89 in
Product Height
6.18 in
Product Width
1.85 in
Product Weight
1 lb
Warranty
Eaton Selling Policy 25-000, one (1) year from the date of installation of the Product or eighteen (18) months from the date of shipment of the Product, whichever occurs first.
Certifications
UL Recognized cUL Recognized
Special features
12 Max point sensors, 4 trip relays
Type
Point sensor unit
Product Category
Arc Flash Relay
Number of inputs
12 point sensor
Number of outputs
4 trip relays
Frequency rating
50/60 Hz
Voltage rating
18-72 Vac/dc
Eaton Specification Sheet - EAFR-101
Selling Policy 25-000 - Distribution and Control Products and Services
The 12 point sensor inputs and four trip relays deliver comprehensive arc flash protection across complex switchgear configurations, enabling precise trip coordination and faster fault clearing. This translates to improved safety, lower incident energy exposure, and measurable reductions in downtime during maintenance windows. As a point sensor unit with 18-72 Vac/dc input flexibility and 50/60 Hz compatibility, installation is straightforward in a wide range of panel enclosures and architectures, supporting cost-effective deployment across facilities. The UL/cUL recognized certification underpins regulatory compliance, simplifying audits and cross-border installations. Its compact footprint and documented warranty support long-term reliability, reducing lifecycle costs and maintenance overhead. Industry practitioners benefit from clear diagnostics and scalable protection topology that aligns with modern arc flash programs and risk-management strategies.
