Eaton ECHF112 Flexible Fixture Support - Hazardous/Classified Locations
Part Number: ECHF112
Quick Summary
ECHF112 is a flexible fixture support for explosion-proof lighting used in hazardous locations. It helps engineers install pendant luminaires with adjustable routing while simplifying service access in restricted or harsh environments. This model carries NEC/CEC compliance and NEC hazardous ratings, including Class I, Division 1 and related divisions, ensuring code-conforming operation. The 12" flexible length, 1/2" nipple, and brass construction deliver installation versatility and durability, while the 125 lb luminaire weight rating supports a broad range of industrial fixtures. For teams seeking reliable, compliant luminaire supports, ECHF112 reduces downtime and improves long-term maintenance planning in oil and gas, chemical, and processing facilities.
Product Information
Extended Description
ECHF112 Eaton: Eaton Crouse-Hinds series ECHF flexible fixture support, 12" flexible length, 125 lb, Brass, Pendant mount, 1/2"
Product Name
Eaton Crouse-Hinds series ECHF flexible fixture support
Catalog Number
ECHF112
UPC
782274257907
Product Weight
2.5 lb
Area classification
Hazardous/Classified Locations
Standards type
NEC/CEC
NEC hazardous rating
Class I, Division 1 Class I, Division 2 Class II, Division 1 Class II, Division 2 Class III
Mounting Type
Pendant
Flexible length
12"
Nipple size
1/2"
Luminaire rated weight
125 lb
Material
Brass
Crouse-Hinds series ECHF Explosionproof Flexible Fixture Supports catalog page
ECHF Explosionproof Flexible Fixture Supports Canadian certification
ECHF Explosionproof Flexible Fixture Supports Canadian certification
IF 556 - ECHF Flexible Support
Eaton Specification Sheet - ECHF112
Feature: 12" flexible length provides versatile routing; Business Impact: enables simpler cable tray and conduit management, reducing field modifications; Application: ceiling and overhead runs in hazardous locations. Feature: Pendant mounting supports common industrial luminaires; Business Impact: faster installation and easier alignment; Application: electrical rooms and hazardous-area ceilings. Feature: Brass material offers corrosion resistance and robustness; Business Impact: longer service life in challenging environments, lower replacement costs; Application: chemical plants and offshore facilities. Feature: 125 lb luminaire rated weight ensures compatibility with mid- to high-weight fixtures; Business Impact: reduces the need for multiple support parts, cutting inventory and labor costs; Application: heavy-duty lighting systems. Feature: NEC/CEC compliance and Class I, Division 1/2; Business Impact: regulatory assurance and risk mitigation; Application: projects requiring hazardous-location certification. Feature: 1/2" nipple size supports standard conduit fittings; Business Impact: simplifies integration with existing infrastructure; Application: retrofit or new installations in industrial plants.
Get a Quick Quote for a Eaton ECHF112
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton ECHF112?
Enquire Now
FAQs
The ECHF112 installs as a pendant-mounted fixture support using a standard 1/2" nipple. Fix the support to a rated structure, route the luminaire wiring through approved conduits, and attach the luminaire to the brass fixture arm. Ensure the installation adheres to NEC/CEC requirements for Class I, Division 1/2 and other applicable classifications for safe operation.
Yes. The ECHF112 is designed for Hazardous/Classified Locations with NEC/CEC standards. It supports NEC hazardous ratings including Class I, Division 1 and related divisions, ensuring proper regulatory compliance for installation in demanding environments such as chemical plants and refineries.
The ECHF112 is rated for luminaire weights up to 125 lb and is manufactured from brass. This combination delivers durable, corrosion-resistant performance suitable for challenging locations while supporting a broad range of fixture types.
Yes. The 125 lb weight rating and pendant mounting capability support a wide range of luminaires, including common LED and HID fixtures used in industrial facilities. Always verify total fixture weight and mounting compatibility with your specific luminaire model.
ECHF112 comes with catalogs, installation instructions, and datasheets. Use the IF 556 instruction sheet for flexible support guidance and consult the Eaton specification sheet for detailed performance data and installation recommendations to ensure compliant, efficient deployment.
