Eaton ECHF14 Flexible Fixture Support - Hazardous Locations
Part Number: ECHF14
Quick Summary
Eaton ECHF14 Flexible Fixture Support is a reliable pendant mounting solution designed to secure luminaires in hazardous locations. Engineers often struggle with weight, certification, and installation constraints when deploying explosionproof fixtures, which can slow projects and elevate risk. With NEC/CEC compliance and hazard ratings for Class I Division 1 and Division 2, Class II Division 1 and 2, plus Class III, this fixture support helps meet strict regulatory requirements across global facilities. Its compact 4-inch flexible length and brass construction deliver durability, while pendant mounting simplifies retrofits and reduces on-site labor. Aligning with Eaton’s ECHF family provides a scalable, maintenance-friendly option for industrial lighting and emergency systems, smoothing procurement and installation processes.
Product Information
Extended Description
ECHF14 Eaton: Eaton Crouse-Hinds series ECHF flexible fixture support, 4" flexible length, 125 lb, Brass, Pendant mount, 1/2"
Product Name
Eaton Crouse-Hinds series ECHF flexible fixture support
Catalog Number
ECHF14
UPC
782274257303
Product Length/Depth
10 in
Product Height
0.001 in
Product Width
0.001 in
Product Weight
1.85 lb
Area classification
Hazardous/Classified Locations
Standards type
NEC/CEC
NEC hazardous rating
Class I, Division 1 Class I, Division 2 Class II, Division 1 Class II, Division 2 Class III
Mounting Type
Pendant
Flexible length
4"
Nipple size
1/2"
Luminaire rated weight
125 lb
Material
Brass
Crouse-Hinds series ECHF Explosionproof Flexible Fixture Supports catalog page
ECHF Explosionproof Flexible Fixture Supports Canadian certification
ECHF Explosionproof Flexible Fixture Supports Canadian certification
IF 556 - ECHF Flexible Support
Eaton Specification Sheet - ECHF14
Feature → Business Impact → Application: The ECHF14 integrates a 4-inch flexible length and pendant mounting, enabling easier routing and mounting in tight or complex ceiling layouts. This reduces installation time and labor costs while improving fixture alignment in demanding environments. Application: hazardous industrial plants with limited ceiling space. Feature → Business Impact → Application: Brass construction and a 125 lb luminaire weight rating deliver robust durability in corrosive or harsh atmospheres, reducing premature replacement needs and downtime. Application: heavy luminaires in chemical processing or refining facilities. Feature → Business Impact → Application: A 1/2-inch nipple size standardizes connections within the ECHF family, simplifying replacements and spares management. Application: retrofit or expansion projects across multiple sites. Feature → Business Impact → Application: NEC/CEC compliance and detailed hazardous location ratings (Class I Div 1/2, Class II Div 1/2, Class III) mitigate regulatory risk and support tender and audit readiness. Application: projects requiring rigorous electrical code adherence. Feature → Business Impact → Application: Pendant mounting and a 10-inch product length provide flexible installation options for overhead luminaire supports, enabling easier alignment with existing equipment and reduced modification needs. Application: retrofit installations in manufacturing, logistics, and process facilities.
Get a Quick Quote for a Eaton ECHF14
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton ECHF14?
Enquire Now
FAQs
The ECHF14 is designed for pendant mounting in hazardous locations. Begin by securing the support to a suitable structural point, attach the 1/2" nipple to the fixture, and route the 4" flexible length to the luminaire. Follow IF 556 instructions for Eaton Crouse-Hinds ECHF fittings and ensure Class I/II/III ratings are observed during mounting.
ECHF14 carries NEC/CEC standards with hazardous location ratings for Class I Division 1 and 2, Class II Division 1 and 2, and Class III, suitable for Hazardous/Classified Locations. Canadian certifications are also available per UL listings, supporting global projects and cross-border installations.
Yes, the ECHF14 is specifically designed for pendant mounting. It supports a luminaire weight rating of 125 lb, making it suitable for mid to heavy-duty hazardous-location luminaires while maintaining secure, code-compliant installation.
Key specs include a 4" flexible length, 1/2" nipple size, brass material, and a 125 lb luminaire weight rating. The product length/depth is 10 in, with a very compact profile for overhead mounting; weight is approximately 1.85 lb per unit.
The ECHF14 provides regulatory compliance, durable brass construction, and straightforward installation, reducing field labor and downtime. Its compatibility with Eaton’s ECHF family supports scalable deployment across sites, lowering maintenance costs and extending luminaire life in hazardous environments.
