Eaton ECHF24 Flexible Fixture Support - Hazardous Locations
Part Number: ECHF24
Quick Summary
The ECHF24 flexible fixture support from Eaton provides secure luminaire mounting in hazardous locations for industrial facilities. End users often confront rigid supports that hinder installation in tight spaces and complicate maintenance tasks. This product carries NEC/CEC compliance and UL listings for Class I, Division 1 and 2, Class II, Division 1 and 2, and Class III, reflecting its suitability for hazardous/classified locations. Its 4 inch flexible length, 3/4 inch nipple, brass construction, and pendant mount simplify routing around structural obstacles while supporting luminaires up to 125 pounds. These attributes translate to faster installations, reduced rework, and lower lifecycle costs across demanding industrial lighting deployments.
Product Information
Extended Description
ECHF24 Eaton: Eaton Crouse-Hinds series ECHF flexible fixture support, 4" flexible length, 125 lb, Brass, Pendant mount, 3/4"
Product Name
Eaton Crouse-Hinds series ECHF flexible fixture support
Catalog Number
ECHF24
UPC
782274257600
Product Weight
2.9 lb
Area classification
Hazardous/Classified Locations
Standards type
NEC/CEC
NEC hazardous rating
Class I, Division 1 Class I, Division 2 Class II, Division 1 Class II, Division 2 Class III
Mounting Type
Pendant
Flexible length
4"
Nipple size
3/4"
Luminaire rated weight
125 lb
Material
Brass
Crouse-Hinds series ECHF Explosionproof Flexible Fixture Supports catalog page
ECHF Explosionproof Flexible Fixture Supports UL certification
ECHF Explosionproof Flexible Fixture Supports UL certification
IF 556 - ECHF Flexible Support
Eaton Specification Sheet - ECHF24
Feature → Business Impact → Application: The 4 inch flexible length and 3/4 inch nipple give adjustable mounting reach, allowing precise alignment of luminaires without extra mounting hardware. This reduces on-site labor time and cut-ins, lowering installation costs and downtime. Ideal for pendant-mounted fixtures in plants with tight overhead clearances, ductwork, or spanning beams where rigid supports would require rework. Feature → Business Impact → Application: Brass construction delivers durability and corrosion resistance in harsh environments, extending service life and minimizing maintenance cycles. The rugged material choice translates into fewer replacements in chemical processing, oil & gas, mining, and offshore facilities, delivering predictable total cost of ownership. This compatibility note also supports long-term performance in harsh industrial atmospheres. Feature → Business Impact → Application: Pendant mounting simplifies wiring routing and allows easier repositioning during plant changes. The combination with a 4 inch length and 3/4 inch nipple supports flexible alignment while maintaining a clean, code-compliant installation in NEC/CEC environments. Feature → Business Impact → Application: The luminaire rated 125 lb capacity provides confidence for heavier fixtures without compromising safety or performance. This mitigates the risk of mid-life luminaire swaps and reduces downtime during maintenance cycles in manufacturing lines or process areas. Feature → Business Impact → Application: Industry-standard compliance and certified for Hazardous/Classified Locations with UL listings and NEC/CEC standards give procurement teams auditable assurance and streamlined approval processes. Compatibility with Eaton's ECHF line also means smoother spares provisioning and familiar installation practices for contractors.
Get a Quick Quote for a Eaton ECHF24
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton ECHF24?
Enquire Now
FAQs
ECHF24 is designed with a 3/4 inch nipple and pendant mounting, specifically addressing Class I, Division 1 and 2 environments. It aligns with NEC/CEC requirements and UL hazardous location certifications, ensuring safe integration with compatible luminaires and standard conduit fittings in designated zones. Verify compatibility by matching the nipple size, mounting type, and regulator-approved materials to your installation drawings and hazardous area classifications.
Key specs include a 4 inch flexible length, 3/4 inch nipple size, brass material, pendant mounting, and a luminaire weight rating of 125 pounds. The unit is intended for hazardous/classified locations under NEC/CEC, with UL certifications for explosion-protected use. When planning, confirm the luminaire weight, mounting clearance, and environmental exposure to ensure sustained performance and compliance.
ECHF24 excels in industries with hazardous atmospheres, such as chemical processing, oil and gas, refineries, mining, and offshore facilities. It provides flexible luminaire support for pendant-mounted fixtures, enabling easier routing around ductwork and equipment. Its brass construction and UL/NEC/CEC compliance make it a reliable choice for environments demanding robust, compliant lighting hardware.
ECHF24 carries NEC/CEC compliance and UL listings for Hazardous Locations, covering Class I, Division 1 and 2, Class II, Division 1 and 2, and Class III. It is designed for Hazardous/Classified Locations and supports area classifications accordingly. This combination helps ensure safe operation, regulatory alignment, and streamlined procurement in regulated industrial settings.
The 4 inch flexible reach and 3/4 inch nipple reduce installation time and material complexity, while the brass durability lowers maintenance and replacement cycles. The pendant mounting and heavy-luminaire capacity minimize rework during commissioning and future changes, delivering a lower total cost of ownership in hazardous-area lighting projects.
