Eaton EDCC10 Fuse - 20 kAIC CE RoHS Certified
Part Number: EDCC10
Quick Summary
EDCC10 fuse provides precise overcurrent protection for control panels and industrial equipment. Engineers struggle with selecting fuses that minimize nuisance trips while preserving uptime. This device is CE marked and RoHS compliant, with CSA certification and UL Listed. As part of Eaton's Edison EDCC family, it supports reliable installation, easy sourcing, and lower total cost of ownership. Specifications like 10 A amperage rating and 20 kAIC interrupt current provide robust protection for common control circuits. With 600 VAC and 300 VDC ratings, it covers both AC and DC feeders in industrial environments. Non-indicating design minimizes visual signal clutter for panel builders while maintaining diagnostic clarity during maintenance.
Product Information
Extended Description
EDCC10 Eaton: Eaton Edison EDCC fuse, Non-indicating, 10 A, Class CC, 20 kAIC, Standard, 600 V, 300 Vdc
Product Name
Eaton Edison EDCC fuse
Catalog Number
EDCC10
UPC
782634808251
Product Length/Depth
1.5 in
Product Height
0.41 in
Product Width
0.41 in
Product Weight
0.19 lb
Warranty
No warranty
Compliances
CE Marked RoHS Compliant
Certifications
CSA Certified UL Listed
Amperage Rating
10 A
Interrupt rating
20 kAIC
Voltage rating
600 Vac, 300 Vdc
Packaging type
Standard
Class
Class CC
Fuse indicator
Non-indicating
Special features
Non-indicating
Feature → 10 A amperage rating combined with a Class CC non-indicating design delivers a compact, standard solution for small-control circuits. Business Impact → Reduces mis-sizing risk and simplifies stocking for OEMs and integrators, enabling faster panel builds and maintenance planning. Application → Ideal for control panels, PLC interfaces, and motor starter circuits in factory automation. Feature → 20 kAIC interrupt rating provides robust short-circuit withstand capability. Business Impact → Enhances system resilience, lowers probability of nuisance fault clearance, and supports safer power distribution. Application → Suitable for feeders and protection schemes in industrial environments with higher fault currents. Feature → Dual voltage ratings of 600 VAC and 300 VDC expand applicability. Business Impact → Enables one part to cover mixed AC/DC installations, reducing part variety and procurement complexity. Application → Appropriate for mixed-control grids, DC bus applications, and equipment with both AC and DC inputs. Feature → Comprehensive certifications (CE, RoHS, UL Listed, CSA Certified) support regulatory compliance. Business Impact → Simplifies supplier qualification, expedites audits, and strengthens quality assurance programs. Application → Critical for medical, food, or heavy-industrial facilities requiring traceable approvals. Feature → Physical and packaging design (1.5 in length, 0.41 in width, 0.41 in height; standard packaging). Business Impact → Facilitates panel fit, compact layouts, and predictable shipment sizing, reducing assembly time. Application → Ready-to-install in standard Edison EDCC fuse holders and panel rails.
Get a Quick Quote for a Eaton EDCC10
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton EDCC10?
Enquire Now
FAQs
The Eaton EDCC10 fuse is a non-indicating 10 A Class CC fuse designed for electrical protection in control panels and industrial equipment. It supports up to 20 kAIC interrupt rating and 600 VAC / 300 VDC ratings, making it suitable for mixed AC/DC circuits in automation cabinets, motor control centers, and feeders. It aligns with CE RoHS, UL listed, and CSA certified standards, easing compliance during procurement and audits.
Key ratings for EDCC10 include a 10 A amperage rating, 20 kAIC interrupt rating, and voltage ratings of 600 VAC and 300 VDC. These specifications enable dependable protection for typical control circuits while accommodating higher fault currents in industrial environments. The ratings also support safe replacement within Eaton’s Edison EDCC fuse family and compatible panel designs.
Yes. EDCC10 supports 300 VDC, in addition to 600 VAC, making it suitable for DC feeders and mixed AC/DC installations common in automation and manufacturing facilities. When selecting fuses for DC circuits, ensure the load current stays within the 10 A rating and consider the 20 kAIC interrupt rating for expected fault currents to maintain quick, reliable disconnection.
The non-indicating design reduces visual signal clutter on the panel, simplifying wiring layouts and freeing up diagnostic space for status indicators and wiring labels. Maintenance team members can still verify protection status through back-end diagnostics or supply chain documentation, while the absence of an indicator can help minimize false fault signals in busy automation environments.
EDCC10 carries multiple regulatory approvals: CE Marking, RoHS compliance, UL Listing, and CSA Certification. These certifications support compliance with European, North American, and international electrical safety and environmental standards, helping OEMs meet supplier qualification, audits, and industry-specific regulatory requirements in sectors such as automotive, industrial manufacturing, and energy.
