Eaton EDCC15 Fuse - UL Listed, Class CC, 20 kAIC
Part Number: EDCC15
Quick Summary
Eaton EDCC15 fuse provides overcurrent protection for electrical panels and machine controls. Selecting the right fuse is critical to minimize nuisance trips and protect downstream equipment. This Edison series fuse carries UL Listed, CSA Certified, and CE RoHS Compliant markings, ensuring compliance across North American and international panel builds. With a 15 A rating and 20 kAIC interrupt capacity, it supports reliable protection in both AC and DC circuits. The non-indicating design keeps panel aesthetics clean while delivering proven performance in standard Class CC fuse blocks, ideal for compact control enclosures and wired automation systems. For cost efficiency and reduced downtime, EDCC15 integrates smoothly with existing Eaton Edison protection schemes and standard wiring practices.
Product Information
Extended Description
EDCC15 Eaton: Eaton Edison EDCC fuse, Non-indicating, 15 A, Class CC, 20 kAIC, Standard, 600 V, 300 Vdc
Product Name
Eaton Edison EDCC fuse
Catalog Number
EDCC15
UPC
782634808275
Product Length/Depth
1.5 in
Product Height
0.41 in
Product Width
0.41 in
Product Weight
0.19 lb
Warranty
No warranty
Compliances
CE Marked RoHS Compliant
Certifications
UL Listed CSA Certified
Amperage Rating
15 A
Interrupt rating
20 kAIC
Voltage rating
600 Vac, 300 Vdc
Packaging type
Standard
Class
Class CC
Fuse indicator
Non-indicating
Special features
Non-indicating
Feature: 15 A amperage rating. Business Impact: Precise protection for control circuits prevents nuisance trips and minimizes component damage. Application: PLC power feeds and sensor circuits in automation panels. Feature: 20 kAIC interrupt rating. Business Impact: High fault current tolerance reduces the risk of cascading failures in heavy machinery. Application: Main feeders and motor drives in manufacturing lines. Feature: 600 Vac / 300 Vdc voltage rating. Business Impact: One fuse supports both AC and DC powered equipment, simplifying stocking and versatility. Application: Mixed electrical racks and DC bus applications. Feature: Class CC, non-indicating. Business Impact: Compact form factor and low maintenance with unobtrusive panel integration. Application: Standard Eaton Edison fuse blocks in control panels. Feature: Packaging type Standard. Business Impact: Easy procurement and consistent installation in high-volume environments. Application: OEM panel builds and service centers. Feature: Certifications UL Listed, CSA Certified, CE RoHS Compliant. Business Impact: Ensures regulatory compliance and customer acceptance across markets. Application: Industrial OEMs targeting global deployment. Feature: Physical dimensions 1.5 in length, 0.41 in width, 0.41 in height; Weight 0.19 lb. Business Impact: Predictable fit in dense enclosures and lightweight for reduced mounting stress. Application: Compact control cabinets and small form-factor panels. Feature: Warranty No warranty. Business Impact: Clear terms aid budgeting and procurement planning. Application: Long-term service agreements and maintenance planning.
Get a Quick Quote for a Eaton EDCC15
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton EDCC15?
Enquire Now
FAQs
EDCC15 is a standard Class CC fuse with a 1.5 inch body length and non-indicating design, intended for Edison fuse blocks. Ensure the holder is rated for 15 A and at least 600 VAC (or 300 VDC) per the datasheet, and verify clearance and mounting provisions in the panel. Using the correct footprint minimizes installation time and reduces contact resistance by design.
Key specs are 15 A amperage, 20 kAIC interrupt rating, and voltage rating of 600 VAC / 300 VDC. This combination supports reliable short-circuit protection for typical control circuits and drives, while tolerating high fault currents without welding or fuse failure. Selecting the right interrupt rating ensures selective coordination with upstream devices and minimizes downtime.
Yes, EDCC15 is UL Listed, CSA Certified, and CE RoHS Compliant, signaling broad regulatory acceptance and supplier reliability. While the datasheet doesn’t specify IP or environmental ratings, these certifications help ensure safe integration into compliant control panels and machinery sold in multiple regions. For harsh environments, verify enclosure integrity and derating as part of the system design.
Buyers should verify the panel design aligns with UL/cSA/CE RoHS requirements and that the 600 VAC / 300 VDC rating matches the circuit. The non-indicating nature means no visual fuse status is provided, so consider auxiliary signaling or status indicators if remote monitoring is needed. Ensure proper labeling, documentation, and replacement part availability align with OEM standards.
Using EDCC15 fuses can reduce downtime through reliable overcurrent protection and standardization across panels. With a compact 1.5 inch form factor and compatibility with standard Class CC blocks, inventory management simplifies procurement. Certifications support compliance readiness, potentially reducing regulatory risk and warranty costs across global deployments.
