Eaton EDCC5 Edison Fuse - UL Listed, 5 A Class CC
Part Number: EDCC5
Quick Summary
The Eaton EDCC5 Edison fuse is a non-indicating, 5 A Class CC fuse designed to protect electrical circuits in control panels and industrial equipment. In practice, engineers often struggle with selecting fuses that balance protection with panel space and ease of maintenance. This device delivers reliable overcurrent protection while minimizing panel footprint and installation complexity. CE marking, RoHS compliance, UL Listed, and CSA Certification provide regulatory confidence across global sites, helping you meet regional safety standards. For manufacturers and integrators, the EDCC5 supports streamlined sourcing and consistent performance in automation cabinets, panel boards, and switchgear, delivering predictable protection and long-term total cost of ownership advantages. Efficient protection with straightforward acceptance criteria translates to faster approvals and reduced project risk.
Product Information
Extended Description
EDCC5 Eaton: Eaton Edison EDCC fuse, Non-indicating, 5 A, Class CC, 200 kAIC, Standard, 600 V, 300 Vdc
Product Name
Eaton Edison EDCC fuse
Catalog Number
EDCC5
UPC
782634808176
Product Length/Depth
1.5 in
Product Height
0.41 in
Product Width
0.41 in
Product Weight
0.19 lb
Warranty
No warranty
Compliances
CE Marked RoHS Compliant
Certifications
UL Listed CSA Certified
Amperage Rating
5 A
Interrupt rating
200 kAIC
Voltage rating
600 Vac, 300 Vdc
Packaging type
Standard
Class
Class CC
Fuse indicator
Non-indicating
Special features
Non-indicating
Feature → Business Impact → Application: 1) 5 A amperage rating with a 200 kAIC interrupt capability provides robust protection for small feeders and control circuits, reducing the risk of nuisance trips and equipment damage in automation panels. The result is improved uptime and lower repair costs in manufacturing lines. 2) 600 Vac / 300 Vdc voltage rating expands compatibility across AC and DC control circuits, enabling a single protective device to cover mixed-voltage panels in machine rooms and packaging lines, simplifying procurement. 3) Class CC, non-indicating design saves space and eliminates indicator wiring in dense control panels, cutting installation time and material cost while maintaining clear fault isolation. 4) UL Listed and CSA Certified with CE RoHS compliance ensures compliance across North America and Europe, easing buy-in for multi-site deployments and reducing qualification lead times. 5) Standard packaging and Edison fuse family compatibility promote straightforward replacement and stocking in maintenance inventories, improving spare parts availability and reducing downtime during maintenance windows. 6) No warranty note prompts careful lifecycle planning, encouraging users to pair EDCC5 with a proactive maintenance program to maximize reliability and total cost of ownership.
