Eaton EFD22106 Circuit Breaker - Explosionproof 30A
Part Number: EFD22106
Quick Summary
Eaton EFD22106 circuit breaker is designed to provide explosionproof protection for hazardous location panels in industrial environments. This unit helps simplify compliance while delivering reliable overcurrent protection in tough surroundings. The breaker is suitable for NEC/CEC environments and meets area classifications for Hazardous/Classified Locations, reinforcing safety and regulatory adherence. With a two-gang enclosure, bolted/ground joint cover, and feraloy iron alloy construction, it balances rugged performance with manageable installation. In addition to core protection, this model supports Square D compatibility and a 120/240 Vac rating, delivering cost-effective scalability for multi-circuit panels in demanding facilities.
Product Information
Extended Description
EFD22106 Eaton: Eaton Crouse-Hinds series EFD circuit breaker, 30A, Bolted/ground joint cover construction, Feraloy iron alloy, Square D breaker, Two-gang, Single-pole, Dead end, 3/4", 120/240 Vac
Product Name
Eaton Crouse-Hinds series EFD circuit breaker
Catalog Number
EFD22106
UPC
782274033112
Product Length/Depth
7.19 in
Product Height
6.13 in
Product Width
3 in
Product Weight
14.42 lb
Area classification
Hazardous/Classified Locations
Standards type
NEC/CEC
NEC hazardous rating
Class I, Division 1 Class I, Division 2 Class II, Division 2 Class III Class II, Division 1
NEMA Rating
3 7 9 12
Enclosure
With circuit breaker
Number of gangs
Two-gang
Style
Dead end
Amperage Rating
30 A
Trade size
3/4"
Manufacturer
Square D
Number of poles
Single-pole
Voltage rating
120/240 Vac
Enclosure cover construction
Bolted/ground joint
Enclosure material
Feraloy iron alloy
EFD and EFDC Series Explosionproof Circuit Breakers catalog page
Eaton Specification Sheet - EFD22106
Feature: Explosionproof construction and feraloy iron alloy housing → Business Impact: Enhanced safety and long-term durability in harsh environments, reducing downtime and maintenance costs. Application: Chemical plants and oil/gas facilities where dust, corrosives, and ignition risks are present. Feature: 30 A amperage rating with 3/4" trade size → Business Impact: Predictable protective coordination for branch circuits, improving reliability and reducing nuisance trips. Application: Motor feeding and lighting in hazardous areas where precise current limits matter. Feature: Two-gang enclosure with single-pole breaker → Business Impact: Flexible space utilization and easier panel integration without sacrificing protection, lowering cabinet footprint and installation complexity. Application: Skid-mounted skids and control panels in processing plants. Feature: Bolted/ground joint enclosure cover → Business Impact: Superior sealing against environmental ingress and easier field servicing, lowering preventive maintenance costs. Application: Enclosures exposed to dust, moisture, or chemical vapors. Feature: 120/240 Vac rating with Square D compatibility → Business Impact: Broad compatibility with common industrial loads and simplified spare-part strategy, reducing total cost of ownership. Application: Mixed-voltage control panels and distribution networks in hazardous locations. Feature: NEC/CEC compliance with Hazardous/Classified Locations ratings and NEMA 3, 7, 9, 12 → Business Impact: Streamlined regulatory approvals and safer operation across facility types, minimizing compliance risk. Application: Mining, petrochemical, and offshore facilities requiring certified protection. Insight: Field experience shows that explosionproof EFD breakers deliver measurable uptime gains in hazardous environments due to robust construction and proven fault isolation, while maintaining straightforward maintenance and parts availability. This makes them a compelling choice for projects prioritizing safety, reliability, and lifecycle cost control.
Get a Quick Quote for a Eaton EFD22106
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton EFD22106?
Enquire Now
FAQs
Install the EFD22106 by housing it in the two-gang enclosure with the bolted/ground joint cover secured to maintain the enclosure's integrity. Mount the single-pole breaker on a suitable support, connect conductors per the 120/240 Vac rating, and verify phase, torque, and clearance per NEC/CEC guidelines. Ensure the assembly remains within approved Class I, Division 1/2 locations to preserve hazardous-area certification.
Key specs include 30 A amperage, 3/4" trade size, 120/240 Vac, and a two-gang enclosure with bolted/ground joint construction. The feraloy iron alloy enclosure provides rugged resistance to impact and temperature cycling, while NEC/CEC compliance and NEMA ratings 3, 7, 9, 12 confirm suitability for hazardous/classified locations and demanding industrial applications.
Yes. The EFD22106 is designed for Hazardous/Classified Locations with NEC/CEC compliance and NEMA ratings suitable for exposure to chemicals, dust, and moist environments. Its explosionproof construction, two-gang enclosure, and 120/240 Vac rating make it appropriate for chemical processing rooms, offshore platforms, and other high-risk facilities requiring certified overcurrent protection.
The EFD22106 carries NEC/CEC standards, Hazardous Area ratings (Class I, Division 1 and 2; Class II, Division 2; Class III; Class II, Division 1), and NEMA ratings 3, 7, 9, 12. These certifications ensure safe operation in hazardous locations, compliance with electrical codes, and compatibility with standard industrial panels, reducing regulatory risk and enabling safer maintenance practices.
Maintenance benefits stem from rugged feraloy enclosure construction, reliable 30 A protection, and a design that minimizes field servicing due to bolted/ground joint integrity. ROI is realized through reduced fault downtime, fewer unplanned trips, and a lower total cost of ownership in hazardous environments, supported by widely available spare parts and proven compatibility with Square D components.
