Eaton EFD32104 Circuit Breaker - Hazardous Locations
Part Number: EFD32104
Quick Summary
The Eaton EFD32104 circuit breaker protects equipment in hazardous environments while integrating with standard 120/240 Vac systems. Operators often face safety and compliance challenges in classified areas, where enclosure integrity and reliable fault interruption are critical. This unit is NEC/CEC compliant and rated for Hazardous/Classified Locations, with supporting NEMA ratings of 3, 7, 9, and 12 that help spans across aggressive environments. Designed for a two-gang, dead-end enclosure with bolted/ground joint construction, it simplifies installation and inspection while delivering predictable interrupt protection. For engineers and procurement teams, this translates to reduced downtime, consistent compliance, and scalable protection across multi-panel distributions.
Product Information
Extended Description
EFD32104 Eaton: Eaton Crouse-Hinds series EFD circuit breaker, 15A, Bolted/ground joint cover construction, Feraloy iron alloy, Square D breaker, Two-gang, Single-pole, Dead end, 1", 120/240 Vac
Product Name
Eaton Crouse-Hinds series EFD circuit breaker
Catalog Number
EFD32104
UPC
782274033242
Product Length/Depth
7.19 in
Product Height
6.13 in
Product Width
3 in
Product Weight
14.42 lb
Area classification
Hazardous/Classified Locations
Standards type
NEC/CEC
NEC hazardous rating
Class I, Division 1 Class I, Division 2 Class II, Division 2 Class III Class II, Division 1
NEMA Rating
3 7 9 12
Enclosure
With circuit breaker
Number of gangs
Two-gang
Style
Dead end
Amperage Rating
15 A
Trade size
1"
Manufacturer
Square D
Number of poles
Single-pole
Voltage rating
120/240 Vac
Enclosure cover construction
Bolted/ground joint
Enclosure material
Feraloy iron alloy
EFD and EFDC Series Explosionproof Circuit Breakers catalog page
Eaton Specification Sheet - EFD32104
Feature: 15 A amperage rating and 1" trade size provide targeted protection for low-power control circuits within confined spaces. Benefit: minimizes nuisance tripping and maximizes panel density, delivering reliable protection with compact footprint. Application: instrumentation panels in chemical processing and oil & gas facilities where space and reliability matter. Feature: Explosion-proof EFD series design with bolted/ground joint enclosure. Benefit: enhances safety by preventing ignition sources from escaping the enclosure in hazardous locations. Application: critical power distribution in the field, including oil refineries and mining operations. Feature: Feraloy iron alloy enclosure construction. Benefit: superior mechanical strength and corrosion resistance under challenging environmental conditions. Application: outdoor or chemically aggressive environments requiring durable protection. Feature: NEC/CEC compliance with Hazardous/Classified Location ratings. Benefit: simplifies regulatory alignment and reduces engineering effort during safety reviews. Application: projects requiring strict electrical safety documentation for hazardous zones. Feature: NEMA ratings 3, 7, 9, 12. Benefit: broad enclosure compatibility and dependable performance across diverse installations. Application: industrial power distribution in harsh environments, including chemical plants and water treatment facilities.
Get a Quick Quote for a Eaton EFD32104
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton EFD32104?
Enquire Now
FAQs
The EFD32104 is designed for a two-gang, dead-end enclosure with bolted/ground joint construction and a 1" trade size. Wiring should follow NEC/CEC guidelines for Class I, Division 1/2 and other relevant classifications. Use proper torque on lugs, ensure proper sealing for the enclosure, and verify compatibility with surrounding equipment to maintain explosion-proof integrity.
The EFD32104 carries NEC/CEC compliance and is rated for Hazardous/Classified Locations with Class I, Division 1/2, Class II Division 2, and Class III protection as applicable. It also aligns with NEMA ratings 3, 7, 9, 12, ensuring suitability for a broad range of environments such as chemical plants, refineries, and mining sites.
Yes. The unit is specified for 120/240 Vac operation and provides a 15 A amperage rating, making it suitable for protecting small feeders and control circuits within standard industrial power distributions.
The bolted/ground joint enclosure provides a tight, secure seal that minimizes ingress in harsh environments, improving long-term reliability. This design supports easier inspection and maintenance, reduces leakage paths for ignition sources, and simplifies retrofits in existing two-gang panels without compromising protection.
Despite a higher initial cost, the EFD32104 offers superior durability in hazardous locations, reducing unplanned outages and maintenance costs. Its robust enclosure, corrosion resistance, and regulatory compliance translate to lower total cost of ownership through fewer replacements, longer service intervals, and streamlined safety documentation for audits.
