Eaton EFDC31105 Circuit Breaker - Explosionproof
Part Number: EFDC31105
Quick Summary
EFDC31105 is a hazardous-location circuit breaker for industrial panels in demanding environments. Engineers often wrestle with meeting safety codes while keeping downtime to a minimum in harsh locations. This device carries NEC/CEC compliance and NEMA ratings for 3, 7, 9 and 12, along with hazardous-location classifications Class I and II, supporting safe operation in oil, gas, and chemical facilities. By combining rugged construction with a compact 1 in trade size, it helps reduce installation time while maintaining code-compliant protection. These attributes translate to lower lifecycle costs and improved reliability for process automation and industrial OEMs.
Product Information
Extended Description
EFDC31105 Eaton: Eaton Crouse-Hinds series EFD circuit breaker, 20A, Bolted/ground joint cover construction, Feraloy iron alloy, Square D breaker, Single-gang, Single-pole, Through feed, 1", 120/240 Vac
Product Name
Eaton Crouse-Hinds series EFD circuit breaker
Catalog Number
EFDC31105
UPC
782274034188
Product Length/Depth
3.5 in
Product Height
7.13 in
Product Width
5 in
Product Weight
8.1 lb
Area classification
Hazardous/Classified Locations
Standards type
NEC/CEC
NEC hazardous rating
Class I, Division 1 Class I, Division 2 Class II, Division 2 Class III Class II, Division 1
NEMA Rating
3 7 9 12
Enclosure
With circuit breaker
Number of gangs
Single-gang
Style
Through feed
Amperage Rating
20 A
Trade size
1"
Manufacturer
Square D
Number of poles
Single-pole
Voltage rating
120/240 Vac
Enclosure cover construction
Bolted/ground joint
Enclosure material
Feraloy iron alloy
EFD and EFDC Series Explosionproof Circuit Breakers catalog page
Eaton Specification Sheet - EFDC31105
20 A amperage rating with a 1" trade size enables precise protection for small control circuits in compact enclosures, reducing nuisance trips and downtime. This leads to faster commissioning and predictable circuit performance in space-constrained panels. The Feraloy iron alloy enclosure and bolted/ground joint construction deliver rugged protection in hazardous environments, aligning with explosionproof requirements and safety standards, which reduces field-service calls and extends equipment life. The through-feed, single-pole, single-gang configuration simplifies installation in retrofit and new builds, with a compact footprint (3.5 in depth, 7.13 in height, 5 in width) that fits standard control enclosures. NEC/CEC compliance and NEMA ratings 3, 7, 9, 12 streamline regulatory planning and documentation, cutting engineering time for risk-sensitive projects. At about 8.1 lb, the unit is manageable to handle on site, while its bolted/ground joint design improves wiring security and reduces re-work during maintenance.
Get a Quick Quote for a Eaton EFDC31105
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton EFDC31105?
Enquire Now
FAQs
EFDC31105 is a single-pole, single-gang breaker with a 1" trade size and through-feed capability, designed to fit many standard hazardous-location panels. It uses a bolted/ground joint enclosure for secure wiring and easier field wiring. When planning installation, confirm panel rating for Class I/Division 1 environments and ensure the enclosure accommodates a 3.5" depth and 7.13" height footprint for safe clearance.
The EFDC31105 provides a 20 A amperage rating with a 1" trade size, and it operates on 120/240 Vac. It is a single-pole device in a single-gang enclosure with through-feed capability and a bolted/ground joint enclosure. Weight is about 8.1 lb, with dimensions around 3.5 in depth, 7.13 in height, and 5 in width.
Yes. EFDC31105 is designed for NEC/CEC compliant installations in hazardous and classified locations. It carries area classifications suitable for Class I, Division 1 and Division 2, Class II Division 2, and Class III environments, along with corresponding NEMA ratings 3, 7, 9, 12, aligning with rigorous industrial safety and performance standards.
The bolted/ground joint enclosure provides a rugged, secure seal that helps protect wiring from dust, moisture, and corrosive atmospheres common in hazardous locations. This design reduces the likelihood of field wiring loosening and improves long-term reliability, which translates to lower maintenance costs and less downtime in tough industrial environments.
Using EFDC31105 delivers compliant protection with reliable interruption in hazardous locations, reducing risk and potential compliance gaps. Its rugged construction, compact footprint, and straightforward installation shorten project timelines, while predictable performance minimizes unplanned outages. Overall, this supports a lower total cost of ownership through safer operation and improved uptime in process automation and energy-intensive facilities.
