Eaton EL12545 EMT Elbow - 1-1/4in, 45°, NEC/CEC
Part Number: EL12545
Quick Summary
The Eaton EL12545 EMT Elbow is a steel 45° bend designed for 1-1/4 inch EMT conduit used in industrial electrical installations. In tight spaces or complex runs, it shortens installation time and improves conduit alignment, reducing field adjustments and rework. This elbow carries NEC/CEC compliance and UL certification documentation and is suitable for Ordinary/Non-Hazardous Locations. Compatible with the Crouse-Hinds EMT fittings family, it provides predictable fit, easy mounting, and supports efficient panel wiring. Its 11 in length and 2 in width aid routing in crowded panels, while the 10.2 in height keeps space planning predictable.
Product Information
Extended Description
EL12545 Eaton: Eaton Crouse-Hinds series EMT elbow, Steel, 45°, 1-1/4"
Product Name
Eaton Crouse-Hinds series EMT elbow
Catalog Number
EL12545
UPC
662277041409
Product Length/Depth
11 in
Product Height
10.2 in
Product Width
2 in
Product Weight
1.26 lb
Area classification
Ordinary/Non-Hazardous Locations
Standards type
NEC/CEC
Conduit type
EMT
Shape
45° angle
Trade size
1-1/4"
Material
Steel
Crouse-Hinds series Elbows and Pulling Elbows - EMT catalog page
Elbows and Pulling Elbows - EMT UL certification (Elbows)
Elbows and Pulling Elbows - EMT UL certification (Elbows)
Eaton Specification Sheet - EL12545
Feature: Steel construction delivers rugged durability for long-term use in industrial environments. This translates to lower replacement costs and reduced maintenance for daily conduit routing. Application: Use the EL12545 for 1-1/4 in EMT conduit runs in control panels, machine halls, and equipment housings where frequent assembly or rework occurs. Feature: 45° bend geometry provides smooth routing around obstructions. Business impact: minimizes tight-radius issues and simplifies cable management. Application: ideal for ladder-rack or wall-mounted conduit installations in manufacturing floors. Feature: Exact 11 in length, 10.2 in height, and 2 in width. Impact: predictable footprint aids pre-fab routing and panel layout. Application: panel builders can plan layouts with confidence. Feature: NEC/CEC compliance and UL certification documentation. Impact: ensures code-compliant wiring and reduces inspection delays. Application: valuable in regulated facilities and non-hazardous locations across automation systems. Feature: Compatibility with Crouse-Hinds EMT fittings family. Impact: streamlines procurement and system integration. Application: install alongside other EMT fittings in industrial automation equipment. Feature: Steel construction with 1.26 lb weight. Impact: lightweight handling during installation and maintenance while maintaining rigidity. Application: ideal for frequent field assembly in compact or dense conduit networks.
Get a Quick Quote for a Eaton EL12545
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton EL12545?
Enquire Now
FAQs
To install the EL12545, verify the conduit is EMT, confirm the 1-1/4 inch trade size, and align the elbow with the desired routing. Attach with standard EMT connectors or couplings, tighten fittings to code-specified torque, and ensure the 45° bend clears panels and supports. Refer to Eaton's EL12545 specification sheet for mounting guidance and compatibility notes to minimize misalignment and rework.
Yes. The EL12545 is NEC/CEC compliant, and UL certification documentation is available for Elbows in the EMT family, as reflected in the product’s certification resources. This combination supports code-compliant installations in Ordinary/Non-Hazardous Locations and helps streamline inspection processes in regulated facilities.
EL12545 is ideal for 1-1/4 inch EMT conduit runs in control panels, machine centers, and automation equipment housings. Its 45° bend aids routing around obstructions in tight spaces, while its steel construction provides durability for ongoing maintenance. Engineers often pair it with other Crouse-Hinds EMT fittings to maintain consistent conduit geometry across panel builds.
Key specs include trade size 1-1/4 inch, material steel, 45° bend, length 11 inches, height 10.2 inches, width 2 inches, and weight 1.26 pounds. It’s designed for EMT conduit and carries NEC/CEC compliance, with ordinary/non-hazardous location suitability. Catalog number EL12545 and UPC 662277041409 are used for ordering and cross-referencing.
Yes. EL12545 is specified for Ordinary/Non-Hazardous Locations and adheres to NEC/CEC standards. This combination ensures safe, code-compliant conduit routing in general industrial environments. For additional verification, consult the UL certification documentation and Eaton’s specification sheet to confirm certification status for your installation site.
