Eaton EPC35A Globe and Guard - IP66 Rated Hazardous Location
Part Number: EPC35A
Quick Summary
EPC35A is an Eaton Crouse-Hinds globe and guard for hazardous-location industrial lighting applications. Maintenance engineers often contend with fragile enclosures and corrosion in harsh environments. This luminaire carries NEC/CEC compliance, IP66 ingress protection, and NEMA 4X ruggedness, enabling safe operation in dusty, wet, and hazardous environments. As a ceiling-mounted globe-and-guard solution, EPC35A supports compliant procurement and reduced downtime across oil, chemical, mining, and heavy manufacturing facilities. By pairing robust materials—copper-free aluminum guard and tempered glass globe—with standard 200W incandescent lamps, it delivers predictable performance and lower lifecycle costs.
Product Information
Extended Description
EPC35A Eaton: Eaton Crouse-Hinds series Pauluhn EP globe and guard, Medium base, 50/60 Hz, Clear tempered glass globe, Cast copper-free alum guard, Incandescent, Copper-free alum, A-21 max. lamp size, Ceiling mount, Shallow dome reflector, 250 Vac, 200W
Product Name
Eaton Crouse-Hinds series Pauluhn EP globe and guard
Catalog Number
EPC35A
UPC
662276391185
Product Length/Depth
16.38 in
Product Height
12.5 in
Product Width
16.38 in
Product Weight
9.4 lb
Area classification
Hazardous/Classified Locations
Standards type
NEC/CEC
NEC hazardous rating
Class I, Division 1 Class I, Division 2
NEMA Rating
4X
Ingress protection (IP) ratings
IP66
Material
Copper-free aluminum
Mounting Method
Ceiling
Reflector type
Shallow dome
Wattage
200W
Lamp type
Incandescent
Lamp size - max
A-21
Base type
Medium
Guard type
With cast guard
Voltage rating
250 Vac
Frequency rating
50/60 Hz
Globe color
Clear
Globe material
Tempered glass
Guard material
Copper-free aluminum
Crouse-Hinds series Pauluhn EP Fluorescent catalog page
IF LBL1415 - EP Fluorescent - Ceiling Mount
Eaton Specification Sheet - EPC35A
IP66 ingress protection and Class I, Division 1/2, plus NEMA 4X ruggedness provide reliable operation in dusty, wet, and hazardous locations. This protection minimizes ingress of dust and water, reducing maintenance cycles and downtime in critical facilities such as refineries, chemical plants, and mining operations. Applications include ceiling-mounted lighting where durable enclosure integrity is required, supporting long service life and safer personnel environments. The EPC35A’s robust sealing and rugged construction help facilities meet strict safety standards while keeping total cost of ownership lower through fewer lamp replacements and enclosure repairs. In practice, users gain consistent illumination and compliance confidence, enabling safer process control and more reliable plant operations. The solution also aligns with procurement requirements for durable, industry-standard components in harsh environments.
Get a Quick Quote for a Eaton EPC35A
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton EPC35A?
Enquire Now
FAQs
EPC35A is designed for hazardous locations with NEC/CEC compliance and IP66/NEMA 4X protection. When installing, ensure the ceiling-mount configuration is secure, the 250 VAC supply is within the 50/60 Hz rating, and the lamp is a maximum 200W incandescent with a medium base (A-21). Confirm enclosure integrity and clearances per local codes to maintain hazardous-location certification.
EPC35A uses a medium-base socket and supports a maximum 200W incandescent lamp (A-21 size). It is rated for 250 VAC and 50/60 Hz operation. The unit is CE NEC/CEC compliant and designed for ceiling mounting with a copper-free aluminum guard and tempered glass globe to withstand demanding industrial environments.
Yes. The EPC35A is built for hazardous or classified locations, offering IP66 ingress protection and a NEMA 4X enclosure, plus a copper-free aluminum guard and tempered glass globe. These features provide durability against dust, water spray, and corrosive atmospheres common in offshore, mining, and chemical plants, while meeting area classifications like Class I divisions 1 and 2.
EPC35A carries NEC/CEC compliance, IP66 ingress protection, and a NEMA 4X rating, along with Hazardous/Classified Location area classification. These certifications confirm safe operation across wet, dusty, and potentially explosive environments, ensuring reliability in high-risk industrial settings and simplifying regulatory compliance during procurement.
The copper-free aluminum guard and tempered glass globe resist corrosion, reducing replacement frequency in harsh environments. IP66 and NEMA 4X protection minimize ingress, lowering cleaning and maintenance needs. With a standard 200W incandescent lamp and ceiling-mount design, installation is straightforward, enabling faster retrofits and predictable long-term operating costs through fewer component failures.
