Eaton EPC37B Globe and Guard - IP66, 4X NEMA Hazardous
Part Number: EPC37B
Quick Summary
The Eaton EPC37B globe and guard delivers rugged illumination for hazardous locations with ceiling-mounted fixtures. In demanding environments, outages and noncompliant equipment can stall production and raise safety risk; this luminaire mitigates both through robust construction and reliable performance. Certified for NEC/CEC compliance, IP66 ingress protection, and NEMA 4X corrosion resistance, it respects strict industrial codes while delivering long service life. Brass guard and tempered glass globe compatibility support durable, maintainable lighting in CNC, petrochemical, and manufacturing environments, reducing downtime and overall operating costs. Its 50/60 Hz operation and 250 VAC rating align with standard industrial power systems, simplifying retrofit and equipment procurement.
Product Information
Extended Description
EPC37B Eaton: Eaton Crouse-Hinds series Pauluhn EP globe and guard, Medium base, 50/60 Hz, Clear tempered glass globe, With cast brass guard, Incandescent, Brass, A-21 max. lamp size, Ceiling mount, 30° angled reflector, 250 Vac, 200W
Product Name
Eaton Crouse-Hinds series Pauluhn EP globe and guard
Catalog Number
EPC37B
UPC
662276391239
Product Length/Depth
6.25 in
Product Height
12.5 in
Product Width
6.25 in
Product Weight
25 lb
Area classification
Hazardous/Classified Locations
Standards type
NEC/CEC
NEC hazardous rating
Class I, Division 1 Class I, Division 2
NEMA Rating
4X
Ingress protection (IP) ratings
IP66
Material
Brass
Mounting Method
Ceiling
Reflector type
30° angle
Wattage
200W
Lamp type
Incandescent
Lamp size - max
A-21
Base type
Medium
Guard type
With cast guard
Voltage rating
250 Vac
Frequency rating
50/60 Hz
Globe color
Clear
Globe material
Tempered glass
Guard material
Brass
Crouse-Hinds series Pauluhn EP Fluorescent catalog page
IF LBL1415 - EP Fluorescent - Ceiling Mount
Eaton Specification Sheet - EPC37B
Hazardous location rating and rugged protection drive uptime for industrial ceilings. The EPC37B globe and guard is designed for NEC Class I, Division 1 and Division 2 environments, combining IP66 ingress protection with NEMA 4X corrosion resistance. This rugged assembly helps keep lighting functional in dusty, damp, or chemical-exposed spaces, reducing unplanned downtime and speeding regulatory compliance across oil, gas, and chemical processing facilities. Durable brass guard and tempered glass globe preserve light output in abrasive or humid environments. The cast brass guard resists impact and corrosion, while the clear tempered globe maintains optical clarity for full lumen delivery. Together, they reduce frequent replacements and support safer maintenance cycles in high-traffic zones. Lamp compatibility and power handling support straightforward upgrades. The unit uses a medium-base, A-21 max incandescent lamp up to 200 watts at 250 VAC and 50/60 Hz, offering predictable illumination levels and easy retrofits in legacy fixtures. Installation flexibility and reflector performance matter in constrained spaces. Ceiling mounting with a 30° reflector orientation provides targeted illumination for aisles, platforms, and workbenches, while the 6.25 in by 12.5 in housing fits standard Pauluhn EP configurations. Compliance, reliability, and lifecycle costs align with industrial procurement goals. With NEC/CEC standards, IP66, NEMA 4X, and durable brass construction, this luminaire minimizes maintenance while maximizing safety and uptime—translating to lower total cost of ownership in hazardous facilities.
Get a Quick Quote for a Eaton EPC37B
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton EPC37B?
Enquire Now
FAQs
To install, power down the circuit and secure the fixture to the ceiling with appropriate mounting hardware. Attach the brass guard and tempered glass globe per the Pauluhn EP configuration, verify a sealed IP66 rating, and connect the 250 VAC supply supporting 50/60 Hz. Ensure the lamp is within the 200W max and the medium base is correctly seated for reliable operation.
The EPC37B supports 250 VAC at 50/60 Hz, with a maximum lamp wattage of 200W using an incandescent lamp. It features a medium base, clear tempered glass globe, and a brass guard. It is designed for IP66 ingress protection and NEMA 4X enclosure ratings, suitable for Hazardous/Classified Locations per NEC/CEC standards.
Yes. The EPC37B is rated for NEC hazardous locations, including Class I Division 1 and Division 2, providing the necessary protection in environments with flammable vapors, gases, or liquids. Its IP66/NEMA 4X construction supports reliable operation under safety-critical conditions.
The EPC37B complies with NEC/CEC requirements for hazardous locations and carries NEMA 4X corrosion resistance with an IP66 ingress protection rating. The brass guard and tempered glass globe are designed for robust industrial use in chemical, petrochemical, and mining facilities, supporting regulatory compliance and safe operation.
Durable brass guard and tempered glass globe minimize damage and reduce frequent replacements, extending service life in harsh environments. The luminaire’s rugged construction lowers maintenance costs, while its compatibility with standard Pauluhn EP ceiling configurations simplifies upgrades and retrofits, delivering lower total cost of ownership in hazardous facilities.
