Eaton EPJ505A502 conduit outlet box - IP66 4X
Part Number: EPJ505A502
Quick Summary
The Eaton EPJ505A502 conduit outlet box protects conduit terminations in hazardous industrial spaces. Many users struggle with maintaining seals, easy maintenance access, and regulatory compliance in harsh environments. With NEMA 4X, IP66 ingress protection, and NEC/CEC hazardous-location ratings, it remains reliable where others fail. Its surface-mount Pauluhn design, 1/2 inch trade size, and two entries streamline installation and long-term service. This enclosure is copper-free aluminum, supporting lightweight handling and corrosion resistance in challenging chemical environments. Ideal for retrofit projects, it pairs with standard Pauluhn EPJ505 catalog offerings and Eaton accessories for scalable protection. For installers, the 180° conduit openings and surface-mount footprint reduce wiring complexity and field modifications.
Product Information
Extended Description
EPJ505A502 Eaton: Eaton Crouse-Hinds series Pauluhn EPJ505 conduit outlet box, Conduit openings 180° apart, Copper-free aluminum, Surface mount, 2 entries, 1/2"
Product Name
Eaton Crouse-Hinds series Pauluhn EPJ505 conduit outlet box
Catalog Number
EPJ505A502
UPC
662276391581
Product Length/Depth
5.69 in
Product Height
5.69 in
Product Width
3.5 in
Product Weight
3 lb
Area classification
Hazardous/Classified Locations
Standards type
NEC/CEC
NEC hazardous rating
Class I, Division 1 Class I, Division 2 Class II, Division 1 Class II, Division 2
NEMA Rating
4X
Ingress protection (IP) ratings
IP66
Trade size
1/2"
Conduit openings
180° apart
Material
Copper-free aluminum
Number of entries
2
Mounting style
Surface
Pauluhn EPJ505 Explosionproof Conduit Outlet Boxes catalog page
Eaton Specification Sheet - EPJ505A502
Explosion-proof construction and robust sealing deliver compliant protection in hazardous locations, translating to reduced downtime and safer operation in chemical plants and oil & gas facilities. The IP66 and NEMA 4X ratings ensure ingress protection against dust, water, and corrosive elements, cutting maintenance costs and extending service intervals. Copper-free aluminum offers a strong weight-to-protection ratio, improving handling during field installs and lowering transport costs without compromising durability in outdoor or harsh chemical environments. The 1/2 inch trade size with two entries and 180° conduit openings enables flexible routing from opposite sides, accelerating wiring and enabling faster panel integration across retrofit projects. Surface mounting simplifies installation in tight or irregular spaces, while compatibility with the Pauluhn EPJ505 family ensures scalable protection and standardized spares for maintenance teams. Industry-standard NEC/CEC compliance supports cross-border projects with reduced design risk.
Get a Quick Quote for a Eaton EPJ505A502
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton EPJ505A502?
Enquire Now
FAQs
Begin by confirming the installation area complies with NEC/CEC hazardous-location requirements. Mount the EPJ505A502 on a suitable surface using standard mounting hardware, then route two 1/2 inch conduits through the two 180° apart entries. Ensure gaskets and seals are correctly seated to maintain IP66/NEMA 4X protection. After wiring, close the enclosure securely and verify ingress protection during commissioning.
EPJ505A502 carries NEC/CEC compliance for hazardous locations, classifying areas as Class I, Division 1 and 2, and Class II, Division 1 and 2. It is rated NEMA 4X and IP66, providing rugged protection against dust and water. These certifications support safe operation in hazardous process environments and ensure regulatory alignment for global projects.
Yes. The EPJ505A502 is manufactured from copper-free aluminum and features a 1/2 inch trade size with two entries, designed for standard 1/2 inch fittings. The copper-free construction aids corrosion resistance while keeping weight manageable for field installations. This compatibility helps streamline procurement and reduces the need for special tools or parts.
The surface-mount design simplifies attachment to walls or panels, reducing mounting hardware and saving installation time. With 5.69 in length and height and 3.5 in width, it fits compact spaces while providing robust protection. Two entries and 180° conduit openings offer flexible wiring layouts, accelerating retrofit projects and minimizing field modifications.
Expect lower maintenance costs due to extended enclosure life from IP66/NEMA 4X protection and corrosion resistance of copper-free aluminum. The rugged construction reduces downtime after exposure to dust, water, or chemicals, while the flexible conduit configuration speeds up installation. Over a project lifecycle, this translates to faster commissioning, fewer part replacements, and improved safety compliance.
