Eaton EPP44A Globe and Guard - IP66, 4X Certified
Part Number: EPP44A
Quick Summary
The Eaton EPP44A globe and guard provides rugged pendant-mounted lighting for hazardous locations. In challenging plants, unreliable fixtures slow maintenance cycles and raise safety risk; this unit reduces downtime with a copper-free aluminum guard and tempered glass globe. It carries NEC/CEC compliance, NEMA 4X, and IP66 ratings, ensuring resistance to corrosive atmospheres, water ingress, and rough handling. The combination of durable construction and a compact 6.25 in width enables easy retrofits in tight spaces, while the 2 x 27W incandescent lamp configuration supports reliable illumination with familiar, easily sourced components. This makes it a practical choice for industrial facilities prioritizing safety, uptime, and total cost of ownership.
Product Information
Extended Description
EPP44A Eaton: Eaton Crouse-Hinds series Pauluhn EP globe and guard, Medium base, 50/60 Hz, Clear tempered glass globe, Cast copper-free alum guard, Incandescent, Copper-free alum, A-19 max. lamp size, Pendant mount, 30° angled reflector, 250 Vac, 100W
Product Name
Eaton Crouse-Hinds series Pauluhn EP globe and guard
Catalog Number
EPP44A
UPC
662276392137
Product Length/Depth
6.25 in
Product Height
12.5 in
Product Width
6.25 in
Product Weight
8.4 lb
Area classification
Hazardous/Classified Locations
Standards type
NEC/CEC
NEC hazardous rating
Class I, Division 1 Class I, Division 2
NEMA Rating
4X
Ingress protection (IP) ratings
IP66
Material
Copper-free aluminum
Mounting Method
Pendant
Reflector type
30° angle
Wattage
2 x 27W
Lamp type
Incandescent
Lamp size - max
A-19
Base type
Medium
Guard type
With cast guard
Voltage rating
250 Vac
Frequency rating
50/60 Hz
Globe color
Clear
Globe material
Tempered glass
Guard material
Copper-free aluminum
Crouse-Hinds series Pauluhn EP Fluorescent catalog page
IF LBL1416 - EP Fluorescent - Pendant Mount
Eaton Specification Sheet - EPP44A
Feature copper-free aluminum guard and tempered glass globe; Business Impact improved corrosion resistance and longer service life in harsh environments; Application hazardous-location pendant lighting in chemical plants and oil facilities. Feature IP66 and NEMA 4X ratings; Business Impact certified protection against dust, water ingress, and corrosive atmospheres; Application outdoor and indoor industrial environments. Feature 2 x 27W incandescent lamps; Business Impact familiar, low-cost maintenance with readily available bulbs; Application walkways, equipment bays, and machine enclosures. Feature pendant mounting; Business Impact streamlined wiring and flexible positioning, reducing installation time; Application retrofit projects and new builds. Feature 30° reflector angle; Business Impact optimized light throw for targeted illumination of critical work areas; Application equipment headers and control panels. Feature A-19 max lamp size and medium base; Business Impact compatibility with standard lamps and easy part replacement; Application retrofit and on-site maintenance programs. Feature 250 Vac and 50/60 Hz; Business Impact dependable power compatibility with common facility electrical networks; Application process plants and laboratories requiring consistent performance.
Get a Quick Quote for a Eaton EPP44A
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton EPP44A?
Enquire Now
FAQs
Installation of the EPP44A uses a standard pendant mounting method designed for hazardous locations. Ensure the fixture is mounted in a location with proper electrical separation, connect to a suitable 250 VAC supply, and follow NEC/CEC guidelines for Class I, Division 1/2 installations. The tempered glass globe and copper-free aluminum guard provide protective barriers, while the 30° reflector angle optimizes light distribution for critical work areas.
The EPP44A uses two 27W incandescent lamps with a medium base (A-19 max). It operates at 250 VAC and 50/60 Hz, is globe-enabled with tempered glass, and features a copper-free aluminum guard. The fixture is designed for pendant mounting and offers a 30° reflector for targeted illumination, balancing brightness with efficiency in industrial settings.
Yes. The EPP44A is rated for Hazardous/Classified Locations with NEC/CEC compliance and an IP66/NEMA 4X protection scheme. This combination provides robust ingress protection against dust and water and supports operation in Division 1/Division 2 areas, making it suitable for chemical processing, oil and gas, and other high-risk facilities.
The fixture carries NEC/CEC standards, Class I Division 1/2 hazardous ratings, IP66 ingress protection, and a NEMA 4X rating. These certifications ensure safe operation in demanding environments, meeting industry and regulatory requirements for hazardous-location lighting and enabling reliable installation in regulated facilities.
The EPP44A uses a copper-free aluminum guard and tempered glass globe, delivering excellent durability and corrosion resistance. The 2x27W incandescent lamps are readily replaceable, reducing maintenance costs, while the IP66/NEMA 4X protection minimizes downtime due to weather and washdowns. Overall, expected ROI comes from extended service life, safer work environments, and lower lifecycle lighting costs.
