Eaton EPP45B Globe & Guard - 30° Reflector IP66
Part Number: EPP45B
Quick Summary
EPP45B globe and guard provides heavy-duty illumination for hazardous-location pendant installations. Facing frequent maintenance, downtime, and harsh ambient conditions, engineers need reliable protection and easy service access. It meets NEC/CEC compliance, IP66 ingress protection, and NEMA 4X corrosion resistance for Class I, Division 1/2 locations, giving you peace of mind under demanding duty. Designed with a brass guard, tempered glass globe, and 200W incandescent lamp compatibility, it complements rugged electrical infrastructure while supporting safe, compliant operation.
Product Information
Extended Description
EPP45B Eaton: Eaton Crouse-Hinds series Pauluhn EP globe and guard, Medium base, 50/60 Hz, Clear tempered glass globe, With cast brass guard, Incandescent, Brass, A-21 max. lamp size, Pendant mount, 30° angled reflector, 250 Vac, 200W
Product Name
Eaton Crouse-Hinds series Pauluhn EP globe and guard
Catalog Number
EPP45B
UPC
662276392168
Product Length/Depth
6.25 in
Product Height
12.5 in
Product Width
6.25 in
Product Weight
23 lb
Area classification
Hazardous/Classified Locations
Standards type
NEC/CEC
NEC hazardous rating
Class I, Division 1 Class I, Division 2
NEMA Rating
4X
Ingress protection (IP) ratings
IP66
Material
Brass
Mounting Method
Pendant
Reflector type
30° angle
Wattage
200W
Lamp type
Incandescent
Lamp size - max
A-21
Base type
Medium
Guard type
With cast guard
Voltage rating
250 Vac
Frequency rating
50/60 Hz
Globe color
Clear
Globe material
Tempered glass
Guard material
Brass
Crouse-Hinds series Pauluhn EP Fluorescent catalog page
IF LBL1416 - EP Fluorescent - Pendant Mount
Eaton Specification Sheet - EPP45B
Brass guard and tempered glass globe deliver rugged protection with improved impact resistance and sealed integrity, making it ideal for pendant-mounted lighting in chemical plants and refineries where equipment takes a beating. IP66 ingress protection and NEMA 4X corrosion resistance safeguard internal components from dust, water, and corrosive atmospheres, enabling longer service life and lower spare parts costs in oil and gas facilities and offshore setups. The 30° reflector directs light downward with reduced glare, boosting task illumination and operator safety for pendant installations along aisles, workbenches, and process lines. Pendant mounting with a medium base and 200W max lamp supports straightforward retrofit and compatibility with existing electrical systems, reducing installation time and training costs in retrofit projects. Compliance with NEC/CEC and Class I, Division 1/2 ratings provides regulatory assurance, lowering risk and enabling safer operations across chemical, mining, and petrochemical environments.
Get a Quick Quote for a Eaton EPP45B
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton EPP45B?
Enquire Now
FAQs
EPP45B is designed for pendant mounting with a medium base and 250 VAC supply. It fits standard electrical boxes used in hazardous locations, simplifying integration with existing conduits and wiring, minimizing retrofit time, and ensuring secure mechanical mounting in Class I, Division 1/2 environments.
Key specs include 200W incandescent lamp capacity, 250 VAC, 50/60 Hz operation, a clear tempered glass globe, brass guard, and a 30° reflector. The unit carries IP66 protection and NEMA 4X enclosure rating, making it suitable for harsh, dust-prone or wet industrial areas.
Yes. The EPP45B is compliant with NEC/CEC standards and carries Class I, Division 1 and Division 2 ratings, along with Hazardous Locations certifications. This ensures safe operation in classified industrial spaces and aligns with global electrical codes.
Ideal for pendant-mounted lighting in chemical plants, refineries, mining operations, and other hazardous environments. Its IP66/NEMA 4X protection, tempered glass globe, and brass guard provide durable illumination in areas with dust, moisture, and potential impact, improving visibility and safety.
The robust brass guard and tempered globe resist damage, while the sealed globe design reduces ingress-related failures. IP66/NEMA 4X protection minimizes downtime and maintenance costs, delivering longer service life and lower total cost of ownership in regulated industrial settings.
