Eaton ER4X-060CF2PR Enclosed Rotary Disconnect - NEMA 4X
Part Number: ER4X-060CF2PR
Quick Summary
The Eaton ER4X-060CF2PR is an enclosed rotary disconnect switch designed to isolate power in industrial control panels. Engineers often struggle with safe, reliable isolation in harsh environments while keeping maintenance downtime to a minimum. This unit offers UL 98 listing and cULus listed status (with pending certification as noted), along with a rugged NEMA 4X enclosure that resists moisture, dust, and corrosion. The combination of a 60 A, 600 V rating and a Class CF fuse configuration, paired with a pistol-style red handle, delivers quick, intuitive operation without compromising safety. It’s a practical choice for capital-intensive panel builds where reliability and compliance matter most.
Product Information
Extended Description
ER4X-060CF2PR Eaton: Eaton Bussmann series enclosed rotary disconnect switch, Fuse type CF, Pistol handle, 600V, 60A, Two-pole, 50/60 Hz, Red, Class CF, NEMA rating 4X, Red
Product Name
Eaton Bussmann series enclosed rotary disconnect switch
Catalog Number
ER4X-060CF2PR
UPC
051712747189
Product Length/Depth
9.84 in
Product Height
8.91 in
Product Width
7.87 in
Product Weight
2.5 lb
Compliances
cULus Listed
Certifications
UL 98 cULus Pending
Amperage Rating
60A
Frequency rating
50/60 Hz
NEMA rating
NEMA 4X
Voltage rating
600 V
Handle color
Red
Fuse configuration
Class CF
Special features
Fuse type CF, Pistol handle
ER4X-060CF2PR~60CF, ENC CCP, 4X, 2POLE
ER4X-060CF2PR~60CF, ENC CCP, 4X, 2POLE
Eaton Specification Sheet - ER4X-060CF2PR
Feature → Business Impact → Application: The ER4X-060CF2PR uses a rugged NEMA 4X enclosure to deliver dependable protection in washdown and outdoor environments, reducing maintenance calls and extending service life for control panels in harsh settings. This two-pole, 60 A switch supports 50/60 Hz operation, enabling seamless integration with standard industrial power circuits while keeping installation complexity low and compatibility high across Eaton Bussmann CF fuse configurations. Benefit: improved safety margins, faster lockout/tagout procedures thanks to a pistol-style red handle, and readily verifiable compliance with UL 98 and cULus requirements. Application: ideal for machine enclosures, panel boards, and process lines in manufacturing where environmental exposure and regulatory standards are critical. The compact footprint and light 2.5 lb weight simplify retrofits and new builds alike.
Get a Quick Quote for a Eaton ER4X-060CF2PR
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton ER4X-060CF2PR?
Enquire Now
FAQs
Install the ER4X-060CF2PR as a two-pole disconnect within a compatible enclosure, ensuring the CF fuse is seated correctly in the fuse holder and that the pistol-style handle is accessible for safe operation. Verify the panel provides a NEMA 4X rated atmosphere and follow lockout/tagout procedures to maintain UL 98 compliant isolation. The unit's 60 A and 600 V ratings align with common industrial distributions, simplifying integration with standard CF fuse configurations.
The device is rated for 60 A continuous current at 600 V with a 50/60 Hz frequency. This supports typical industrial loads while maintaining a safe isolation path when open. The NEMA 4X enclosure provides environmental protection against dust, water, and corrosion, making it suitable for both indoor and outdoor installations in demanding environments.
Yes. The NEMA 4X enclosure rating indicates robust protection against water and corrosion, making it appropriate for outdoor panels and washdown areas. Combine this with UL 98 and cULus listed compliance to ensure both safety and regulatory alignment in harsh industrial settings.
Rely on UL 98 listing and cULus listing (with pending status noted) for safety certification, plus the NEMA 4X enclosure rating for environmental protection. These credentials support compliance in many industrial standard regimes and help ensure reliable performance in harsh operating conditions.
The combination of rugged construction, standard CF fuse compatibility, and a pistol-handled operating mechanism reduces maintenance time and downtime during fuse changes or service. The 9.84 in length, 8.91 in height, and 7.87 in width provide a compact footprint for panel space optimization, while the lightweight 2.5 lb weight simplifies installation and reduces handling risk, contributing to lower lifecycle costs and faster return on investment.
