Eaton ER53080UW Enclosed Rotary Disconnect - NEMA 4X
Part Number: ER53080UW
Quick Summary
The Eaton enclosed rotary disconnect switch ER53080UW safely isolates electrical circuits in industrial equipment. Maintaining reliable isolation while minimizing space and downtime is a common challenge for panel builders and maintenance teams. CSA Certified and UL Listed with a NEMA 4X stainless-steel enclosure, it resists corrosion and harsh washdown conditions. With an 80 A rating and HP range up to 40 hp across 208–600 V in a three-pole format, it supports compact, scalable motor-control solutions while reducing part counts and installation time. For engineers seeking reliable protection and easy service in harsh environments, the ER53080UW delivers business value through safer startups and lower maintenance costs.
Product Information
Extended Description
ER53080UW Eaton: Eaton enclosed rotary disconnect switch, 80A, NEMA 4X, Stainless steel, Max HP:15, 20, 40, 40 hp (@208,240,480,600 V), Three-pole, Product category: enclosed rotary non-fusible, R-Series, 600 V
Product Name
Eaton enclosed rotary disconnect switch
Catalog Number
ER53080UW
UPC
786685466132
Product Length/Depth
15.4 in
Product Height
8.4 in
Product Width
10 in
Product Weight
8.4 lb
Warranty
Eaton Selling Policy 25-000, one (1) year from the date of installation of the Product or eighteen (18) months from the date of shipment of the Product, whichever occurs first.
Certifications
CSA Certified UL Listed
Enclosure
NEMA 4X
Enclosure material
Stainless steel
Number of poles
Three-pole
Series
R-Series
Type
Enclosed rotary disconnect
Amperage Rating
80A
HP rating - max
15, 20, 40, 40 hp (@208,240,480,600 V)
Voltage rating
600 V
Product Category
Enclosed rotary non-fusible
Commercial Distribution, Switching Devices, Volume 2, Tab 1
Switching Devices Flex Center
Eaton Specification Sheet - ER53080UW
Feature: 80A amperage rating with a three-pole, non-fusible design. Business impact: Provides reliable isolation without relying on fuses, enabling faster lockout/tagout procedures and reducing downtime during motor servicing. Application: Motor circuits in conveyors, packaging lines, and automation equipment. Feature: NEMA 4X stainless-steel enclosure. Business impact: Delivers exceptional corrosion resistance and washdown durability, extending service life in harsh or outdoor environments. Application: Outdoor installations, chemical processing, and food & beverage equipment where cleaning with water jets is common. Feature: Enclosed rotary disconnect in the R-Series line. Business impact: Standardized form factor supports easier maintenance, faster spare-part sourcing, and smoother retrofits. Application: Replacements in existing Eaton switchgear and new panel builds. Feature: Certifications and warranty. Business impact: CSA Certified UL Listed assurance plus a one-year (or 18 months from shipment) warranty minimizes risk and supports compliance planning. Application: Industrial compliance programs and procurement standards. Feature: Compact dimensions and weight. Business impact: Small footprint enables flexible mounting and reduced panel depth, saving cabinet space and assembly time. Application: Control panels with limited enclosure area in machine tooling and material handling. Feature: 600 V rating and 15–40 hp compatibility. Business impact: Supports a wide motor-load range while reducing the number of discrete components in the drive chain. Application: Medium-voltage motor control across multiple voltages in automotive, packaging, and process industries.
Get a Quick Quote for a Eaton ER53080UW
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton ER53080UW?
Enquire Now
FAQs
Yes. The ER53080UW is a three-pole, 600 V rated enclosed rotary disconnect designed for motor circuits up to 40 hp across multiple voltages. It fits typical panel layouts and simplifies wiring by consolidating isolation into a single, non-fusible switch.
The 80A rating provides ample headroom for motor starting currents and load transients common in conveyors. As a non-fusible, enclosed rotary switch, it offers predictable energization and de-energization, reducing wear on contact surfaces and improving uptime during routine maintenance.
The NEMA 4X stainless enclosure is ideal for washdown areas, outdoor installations, and corrosive environments such as chemical processing or food and beverage processing. Its corrosion resistance helps extend service life and lowers maintenance frequency in tough settings.
The unit is CSA Certified and UL Listed, confirming adherence to electrical safety and performance standards. These certifications streamline approvals in regulated facilities and support competitive procurement by meeting common compliance requirements.
By combining robust corrosion resistance, straightforward non-fusible isolation, and a compact footprint, the ER53080UW reduces maintenance intervals and spare-parts inventory while lowering downtime during motor servicing and panel upgrades, delivering tangible total cost of ownership benefits for mid-range industrial applications.
