Eaton ES5T2R1F3 Elevator Control Switch - UL Listed

Feature: 120 Vac coil fire-safety interface relay. Business Impact: Enables immediate, reliable signaling between fire systems and the elevator control circuit, reducing fault-response time and improving safety margins. Application: Building fire safety interfaces and elevator recall scenarios where immediate response is critical. Feature: Three-pole fire alarm voltage monitoring relay. Business Impact: Provides redundant monitoring to ensure alarms trigger only when required, minimizing false trips and unnecessary elevator downtime. Application: High-occupancy commercial towers and hospital complexes. Feature: Main lug capacity (2) #1/0-300 kcmil or (1) #1/0-750 kcmil Al/Cu. Business Impact: Supports large feeder cables, accommodating modern elevator loads and future upgrades without rewiring. Application: New installs and retrofits in mid- to high-rise systems. Feature: 400 A, 208 V rating. Business Impact: Handles demanding elevator motor circuits with solid protection margins, improving system reliability. Application: Heavy-duty elevator feeders in transportation hubs and high-rise buildings. Feature: NEMA 1 enclosure and no pilot light or neutral lug. Business Impact: Simplifies installation, reduces maintenance points, and lowers leakage risks. Application: Indoor equipment rooms and control panels where space and wiring clarity matter. Feature: UL 98 certification and UL Listed (E182262). Business Impact: Guarantees safety compliance for code-required elevator controls, speeding approvals. Application: Public buildings and facilities with strict safety audits. Feature: Catalog notes on oversize enclosure and transformer mounting. Business Impact: Facilitates integration with power transformers and terminal blocks, reducing install time. Application: Systems requiring integrated fire-safety power interfaces. Feature: Optional neutral lug size and absence of neutral complications. Business Impact: Streamlines wiring schemes and lowers misconnection risk. Application: Retrofit projects with variable line/load configurations. Feature: 12.69 in L, 54.63 in H, 25.21 in W, 150 lb weight. Business Impact: Clear space planning and robust mounting in equipment rooms, minimizing vibration and misalignment. Application: New builds and upgrades in controlled environments. Theme: The combination of safety certifications, robust current handling, and install-friendly design supports faster, compliant, and cost-efficient elevator control modernization.
