Eaton EZ1201GY EZLink modular toggle switch - cULus Listed
Part Number: EZ1201GY
Quick Summary
EZLink modular toggle switch is a compact control device that delivers reliable on/off functionality for control panels in industrial environments. Engineers often grapple with wiring complexity, space constraints, and downtime during upgrades. It carries cULus Listed status with NOM and Federal Specification W-C-596G, reinforcing regulatory compliance. Designed for 15A loads at 120-277 Vac in single-pole circuits, its gray housing supports quick installs and consistent panel aesthetics, enabling safer, faster deployments and lower maintenance across new builds and retrofits.
Product Information
Extended Description
EZ1201GY Eaton: Eaton EZLink modular toggle switch, 15 A, 120-277 Vac, 60 Hz, single-pole, three-wire, gray
Product Name
Eaton EZLink modular toggle switch
Catalog Number
EZ1201GY
UPC
032664009327
Product Length/Depth
1.91 in
Product Height
4.4 in
Product Width
1.75 in
Product Weight
0.192 lb
Certifications
cULus Listed NOM Federal Specification Classification W-C-596G
Amperage Rating
15A
Voltage rating
120-277 Vac
Number Of Poles
Single-pole
Color
Gray
Modular EZLink design enables rapid panel assembly and straightforward retrofits, cutting wiring errors and installation time. This translates into reduced commissioning costs and faster time-to-value in control panel projects. Ideal for replacement of legacy switches or as part of a modular device upgrade in factories and packaging lines. With a 15A amperage rating and a 120-277 Vac, 60 Hz voltage range, the EZ1201GY is suited for lighting, signaling, and small motor control in industrial panels. The single-pole configuration simplifies wiring diagrams and reduces miswiring risk, improving reliability across line starts and resets. This versatility supports fast upgrades and consolidates spare part inventories. Compact dimensions and gray housing deliver a neat panel presentation while easing fit in tight spaces (1.91 in depth, 1.75 in width, 4.4 in height). Easy mounting and compatibility with modular devices simplifies installation, reducing on-site labor hours. Documentation and support are readily available via Eaton’s EZ Link brochure and data sheets, aiding planning and lifecycle management.
Get a Quick Quote for a Eaton EZ1201GY
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton EZ1201GY?
Enquire Now
FAQs
The EZ1201GY is a single-pole toggle switch designed for modular device installations in control panels. It supports standard wiring practices for 15A, 120-277 Vac circuits and aligns with Eaton’s EZLink modular devices, enabling straightforward substitutions or upgrades in existing panel architectures. Its compact dimensions and gray housing help ensure a clean, scalable installation in crowded or retrofitted panels.
The EZ1201GY is rated for 15A and operates over a voltage range of 120-277 Vac at 60 Hz. This makes it suitable for lighting, signaling, and small motor control circuits in industrial control panels, while delivering reliable performance across common industrial loads.
Yes. With a 15A rating and 120-277 Vac capability in a single-pole configuration, the EZ1201GY is well-suited for machine control panels, conveyors, and lighting circuits found on manufacturing lines. Its modular design supports rapid upgrades and consistent, repeatable installations across multiple line configurations.
The EZ1201GY carries cULus Listed status and complies with NOM and Federal Specification W-C-596G. These certifications help streamline supplier qualification, reduce re-testing during audits, and align with common industrial regulatory requirements, simplifying approval processes for new equipment and retrofits.
The modular EZLink line offers quick install times, simpler field upgrades, and reduced downtime thanks to its standardized form factor and clear wiring pathways. This supports faster commissioning, easier part replacement, and better lifecycle management, backed by Eaton’s brochure resources for planning and maintenance guidance.
