Eaton EZ1203RD EZLink modular toggle switch - cULus Listed
Part Number: EZ1203RD
Quick Summary
The Eaton EZLink modular toggle switch controls 120-277 VAC three-pole circuits in industrial panels. Engineers rely on its modular design to streamline panel assembly and field modifications. Many teams struggle with space constraints, wiring complexity, and slow updates when changes are required. This model carries cULus Listed, NOM, and Federal Specification Classification W-C-596G to meet broad regulatory requirements, offering predictable performance across regions. In addition to compliance, its compact footprint and red actuation provide clear visibility, while the modular EZLink platform enables rapid expansion of control circuits, reducing downtime and lowering total cost of ownership for integrators and end users. Its dual-wire, four-wire capability simplifies wiring topology and reduces misconnection risk in complex panels.
Product Information
Extended Description
EZ1203RD Eaton: Eaton EZLink modular toggle switch, 15 A, 120-277 Vac, 60 Hz, three-pole, four-wire, red
Product Name
Eaton EZLink modular toggle switch
Catalog Number
EZ1203RD
UPC
032664009419
Product Length/Depth
1.91 in
Product Height
4.4 in
Product Width
1.75 in
Product Weight
0.192 lb
Certifications
cULus Listed NOM Federal Specification Classification W-C-596G
Amperage Rating
15A
Voltage rating
120-277 Vac
Number Of Poles
Three-pole
Color
Red
Feature: 15 A amperage rating at 120-277 Vac enables reliable control of lighting and small-motor loads. This rating translates to predictable performance in standard industrial panels, reducing the need for oversizing components. Application-wise, EZ1203RD is well-suited for panel boards and machine controls where compact, compliant switching is required. Feature: Three-pole, four-wire configuration improves fault isolation and power distribution accuracy. This arrangement supports multi-wire circuits and safer isolation in control panels. Application: suitable for three-phase or multicircuit control applications, reducing wiring errors and improving maintenance efficiency. Feature: Red color and visible actuator provide immediate operator feedback, decreasing misoperation risk. This enhances safety in busy control rooms and enclosures. Application: emergency-stop stations, local indicators, and rapid visual confirmation in automated lines. Feature: EZLink modular design enables fast installation and scalable expansion across modular devices. Compatibility with Eaton EZLink devices accelerates wiring, reduces panel depth, and supports rapid field upgrades. Application: modular control systems in new builds and retrofits seeking minimal downtime. Feature: Certifications including cULus Listed, NOM, and W-C-596G ensure regulatory acceptance across North America and international markets. This supports compliance-driven procurement and reduces qualification cycles. Application: certified panels and equipment in industrial automation. Feature: Compact dimensions—1.91 in depth, 1.75 in width, 4.4 in height—and weight of 0.192 lb—facilitate dense panel layouts and simplified mounting. This saves enclosure space and lowers install time. Application: space-constrained control cabinets and panel assemblies.
Get a Quick Quote for a Eaton EZ1203RD
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton EZ1203RD?
Enquire Now
FAQs
For straightforward mounting, plan space for the 1.91 in depth and 1.75 in width while ensuring access to the red actuator for quick status checks. Use standard EZLink modular devices in compatible Eaton enclosures and follow the included wiring diagram to maintain proper four-wire connections and safe, code-compliant terminations.
EZ1203RD is rated for 15 A at 120-277 Vac with a three-pole, four-wire configuration. This allows safe switching of multi-wire circuits and supports both lighting and small-motor control in industrial panels. The device is designed for reliable operation within its rated voltage range across typical control applications.
Yes. The three-pole configuration supports three-phase or multicircuit control, enabling safer fault isolation and streamlined wiring in panel boards. The modular EZLink platform further simplifies integration with other modular devices in Eaton’s ecosystem for scalable automation solutions.
The EZ1203RD carries cULus Listed, NOM, and Federal Specification Classification W-C-596G certifications. These markings validate compliance with North American and federal standards, reducing regulatory risk in procurement and enabling smoother qualification for certified panel assemblies and equipment.
The EZLink modular design enables faster field upgrades, easier replacements, and scalable expansion without rewiring entire panels. This reduces downtime during modifications, shortens project timelines, and lowers total cost of ownership by enabling incremental growth of control circuits in automation systems.
