Eaton EZ5262BK EZLink modular duplex receptacle - cULus
Part Number: EZ5262BK
Quick Summary
The Eaton EZ5262BK EZLink modular duplex receptacle provides reliable 15 A, 125 V power at control panels and workstations. When space is tight or wiring must adapt to changing layouts, modular receptacles reduce rework without sacrificing performance. This device carries cULus Listed and NOM certifications, plus Federal Specification W-C-596G, signaling compliance across North American and government-installed equipment. With a compact footprint and a three-wire NEMA 5-15R configuration, it fits crowded enclosures while delivering consistent power delivery. Leveraging this EZLink module supports faster installations, easier maintenance, and scalable distribution for growing automation systems. Adopting modular outlets like EZ5262BK helps OEMs and integrators cut installation time, improve reliability, and lower lifecycle costs in industrial environments.
Product Information
Extended Description
EZ5262BK Eaton: Eaton EZLink modular duplex receptacle, 15 A, 125 Vac, 60 Hz, NEMA 5-15R, three-wire, black
Product Name
Eaton EZLink modular duplex receptacle
Catalog Number
EZ5262BK
UPC
032664009617
Product Length/Depth
1.09 in
Product Height
4.2 in
Product Width
1.46 in
Product Weight
0.2 lb
Certifications
cULus Listed NOM Federal Specification Classification W-C-596G
Amperage Rating
15A
Voltage rating
125 Vac
Number of wires
3
Color
Black
Feature 15A, 125V, three-wire NEMA 5-15R configuration ensures compatibility with everyday industrial and office equipment. Business impact standardization reduces device inventory and simplifies wiring diagrams, lowering installation risk. Application control panels and workstation power distribution in manufacturing environments. Feature Compact footprint with dimensions 1.09 in depth, 4.2 in height, and 1.46 in width fits tight panel spaces. Business impact enables denser layouts and easier enclosure planning, reducing cabinet size and wiring route complexity. Application panel-mounted power outlets in compact automation solutions. Feature Modular EZLink design supports quick wiring and future upgrades. Business impact accelerates commissioning and minimizes downtime during system changes. Application ideal for scalable power distribution in evolving automation architectures. Feature cULus Listed, NOM, and Federal Specification W-C-596G certifications ensure regulatory compliance. Business impact streamlines procurement and cross-border deployments. Application procurement confidence for integrators and OEMs working in mixed regulatory environments. Feature Color Black provides visual consistency with standard industrial enclosures. Business impact improves panel aesthetics and reduces misidentification in high-density control rooms. Application suitable for equipment racks and wall-mount panels where uniform appearance matters.
Get a Quick Quote for a Eaton EZ5262BK
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton EZ5262BK?
Enquire Now
FAQs
Install with power off, mount the receptacle to a standard knockout or panel location, and connect three wires to the appropriate terminals for a NEMA 5-15R configuration. Verify a secure mechanical fit and proper strain relief to minimize vibration. Follow local electrical codes and Eaton installation guidance for best results.
Yes. The EZ5262BK is cULus Listed and NOM certified, with Federal Specification W-C-596G. This combination supports regulatory compliance in North America and eases procurement for projects requiring government specifications.
The receptacle measures 1.09 inches in depth, 4.2 inches in height, and 1.46 inches in width, with a weight of approximately 0.2 pounds. These compact dimensions help save space in crowded enclosures while maintaining robust electrical performance.
Yes. Designed as a modular duplex receptacle, it supports 15A at 125V with a NEMA 5-15R three-wire configuration, making it suitable for control panels, workstations, and power distribution in industrial settings. Its modular design facilitates scalable layouts and easier maintenance.
Key certifications include cULus Listed, NOM, and Federal Specification W-C-596G. These ensure safety, reliability, and government procurement compatibility, reducing risk in regulated environments and during cross-border deployments.
