Eaton EZ5262SCBK EZLink duplex receptacle - cULus
Part Number: EZ5262SCBK
Quick Summary
EZ5262SCBK is a modular duplex receptacle that provides reliable 15A/125V power in equipment enclosures. In busy control panels, space constraints and wiring congestion can cause downtime and miswiring. It’s cULus Listed and complies with NOM and Federal Specification Classification W-C-596G, delivering safety and regulatory confidence. Designed for modular integration, it pairs with Eaton EZLink devices to improve panel density and speed up installations. For procurement and maintenance teams, the compact form and predictable replacements translate to lower lifecycle costs and less risk. Its standard 125V, 60 Hz operation supports a wide range of industrial loads while reducing wiring overhead.
Product Information
Extended Description
EZ5262SCBK Eaton: Eaton EZLink modular duplex receptacle, 15 A, 125 Vac, 60 Hz, split control, NEMA 5-15R, three-wire, black
Product Name
Eaton EZLink modular duplex receptacle
Catalog Number
EZ5262SCBK
UPC
032664010491
Product Length/Depth
1.09 in
Product Height
4.2 in
Product Width
1.46 in
Product Weight
0.2 lb
Certifications
cULus Listed NOM Federal Specification Classification W-C-596G
Amperage Rating
15A
Voltage rating
125 Vac
Number of wires
3
Color
Black
Feature: 15A, 125V, three-wire NEMA 5-15R configuration provides reliable, standard power delivery in control panels. Business impact: It supports common branch circuits, reducing the need for specialized outlets and minimizing field wiring errors. Application: Ideal for electrical enclosures and equipment racks in manufacturing, packaging, and facilities maintenance. Feature: EZLink modular design enables seamless integration with Eaton modular devices. Business impact: This creates scalable panel architectures with reduced footprint and faster wiring during commissioning. Application: Panel builders and retrofit projects where space and speed matter. Feature: Compact dimensions and lightweight form—1.09 in depth, 4.2 in height, 1.46 in width; weight about 0.2 lb. Business impact: Higher panel density and easier mounting translate to shorter install times and lower labor costs. Application: Enclosures with tight space constraints and dense wiring layouts. Feature: Certifications include cULus Listed, NOM, and Federal Specification Classification W-C-596G. Business impact: Regulatory alignment reduces procurement risk and speeds project approvals across regulated industries. Application: Commercial and industrial installations requiring proven safety and compliance. Feature: Black finish and standard NEMA 5-15R configuration support visibility and compatibility with equipment aesthetics. Business impact: Improves panel readability and reduces misconnection risk in high-mix environments. Application: Electrical closets, control panels, and factory automation cabinets.
Get a Quick Quote for a Eaton EZ5262SCBK
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton EZ5262SCBK?
Enquire Now
FAQs
Power must be OFF before installation. Mount the receptacle in a standard electrical enclosure, align with the panel’s DIN or knockout layout, and connect the three wires to the 15A, 125V circuit (hot, neutral, ground) using appropriate terminals. Secure with the provided hardware and verify grounding continuity to ensure safe operation and reliable NEMA 5-15R performance.
Yes. The EZ5262SCBK is designed for Eaton’s EZLink modular devices ecosystem, enabling scalable power distribution within panel assemblies. This compatibility supports faster wiring, simplified expansion, and reduced panel real estate, making it ideal for both new builds and retrofits in industrial environments.
EZ5262SCBK is cULus Listed and complies with NOM and Federal Specification Classification W-C-596G. These certifications provide regulatory assurance and standards-based safety for commercial and industrial installations, helping with procurement approval and long-term reliability.
The receptacle measures 1.09 inches deep, 4.2 inches high, and 1.46 inches wide, with an approximate weight of 0.2 pounds. The 15A, 125V, three-wire NEMA 5-15R configuration fits standard panel cavities and supports dense mounting in electrical enclosures.
The compact footprint and EZLink compatibility enable higher panel density and faster installation, reducing labor costs. The standard 15A/125V rating supports common loads, while regulatory certifications mitigate procurement risk. Overall, it delivers scalable expansion, easier maintenance, and predictable replacements in industrial power distribution projects.
