Eaton EZ5362CDGN EZLink - cULus Listed
Part Number: EZ5362CDGN
Quick Summary
The Eaton EZLink modular duplex receptacle is a reliable power outlet solution for control panels. Installers often face tight spaces, wiring complexity, and compatibility gaps when integrating modular devices into existing enclosures. This model is cULus Listed, NOM certified, and meets Federal Specification W-C-596G, confirming robust regulatory alignment. With a 20A, 125V rating and NEMA 5-20R configuration, it accommodates common panel loads while remaining straightforward to install. By leveraging the EZLink modular family, manufacturers can standardize on a single receptacle for multiple applications, reducing part numbers and simplifying procurement without sacrificing reliability or performance.
Product Information
Extended Description
EZ5362CDGN Eaton: Eaton EZLink modular duplex receptacle, 20 A, 125 Vac, 60 Hz, dual controlled, NEMA 5-20R, three-wire, green
Product Name
Eaton EZLink modular duplex receptacle
Catalog Number
EZ5362CDGN
UPC
032664010613
Product Length/Depth
1.91 in
Product Height
4.4 in
Product Width
1.75 in
Product Weight
0.2 lb
Certifications
cULus Listed NOM Federal Specification Classification W-C-596G
Amperage Rating
20A
Voltage rating
125 Vac
Number of wires
3
Color
Green
Feature → Business Impact → Application: 20A, 125V, three-wire NEMA 5-20R receptacle delivers industry-standard power delivery that aligns with typical control-panel loads; reduces risk of overloads and improves overall panel reliability. This translates to measurable uptime improvements and lower commissioning costs for OEMs and end users alike. Application: industrial automation enclosures and commercial panels benefit from predictable power distribution and faster wiring diagrams, enabling quicker starts to production lines and service upgrades. Feature → Business Impact → Application: Dual controlled operation provides independent control of the receptacle circuit, enabling safer testing and maintenance routines and supporting obscure safety protocols in machine cells. Application: automation cells and process lines where selective power control minimizes risk during troubleshooting while preserving system availability. Feature → Business Impact → Application: Three-wire grounding enhances safety and reduces potential fault currents, contributing to improved OSHA-compliant installations. Application: wiring layouts in machine shops and system cabinets where strict grounding practices are essential. Feature → Business Impact → Application: Compact footprint with dimensions of 1.91 in depth, 1.75 in width, and 4.4 in height simplifies retrofits in crowded panels and junction boxes, lowering installation time and labor costs. Application: legacy enclosures and new-builds alike where space is at a premium. Feature → Business Impact → Application: Green color and modular EZLink compatibility support quick visual identification and straightforward integration with other modular devices, reducing mis-wiring and facilitating consistency across installations. Application: large-scale data centers, manufacturing floors, and facilities that require standardized power distribution components. Certification & Compliance Context → Business Impact → Application: cULus Listed, NOM, and Federal Specification W-C-596G certifications provide traceable compliance for code-approved installations, reducing audit risk and speeding project approvals. Application: regulated environments and industry-standard panel builds where regulatory adherence is non-negotiable.
