Eaton EZ6262CHBK Decorator Receptacle - cULus Listed
Part Number: EZ6262CHBK
Quick Summary
The Eaton EZLink modular decorator receptacle provides reliable power distribution for commercial outlets. Installers often face space constraints and mismatched faceplates, which drive rework and delays. This unit carries cULus Listed and NOM approvals, plus Federal Specification W-C-596G, helping you meet safety and procurement standards. With 15 A, 125 Vac, 60 Hz operation and a NEMA 5-15R configuration, it integrates with standard wiring and modular faceplates for fast, reliable installations. In practice, EZ6262CHBK supports faster deployments, reduced wiring errors, and lower installed costs for commercial power distribution.
Product Information
Extended Description
EZ6262CHBK Eaton: Eaton EZLink modular decorator receptacle, 15 A, 125 Vac, 60 Hz, half controlled, NEMA 5-15R, three-wire, black
Product Name
Eaton EZLink modular decorator receptacle
Catalog Number
EZ6262CHBK
UPC
032664011023
Product Length/Depth
1.91 in
Product Height
4.4 in
Product Width
1.75 in
Product Weight
0.2 lb
Certifications
cULus Listed NOM Federal Specification Classification W-C-596G
Amperage Rating
15A
Voltage rating
125 Vac
Number of wires
3
Color
Black
Feature: EZLink modular decorator design enables flexible layouts and rapid configuration. Benefit: Reduces wiring complexity and the need for multiple faceplates, cutting project lead times. Application: Office furniture and workstation configurations benefit from quicker deployments and fewer field modifications. Feature: Rated 15 A at 125 Vac and 60 Hz with a NEMA 5-15R. Benefit: Consistent performance under typical loads and predictable thermal behavior in dense power layouts. Application: Data centers, labs, and commercial enclosures where reliability matters. Feature: Half controlled capability. Benefit: Enables selective load control to save energy on peripheral devices and equipment, improving efficiency. Application: Computer rooms, control panels, and workspace power strips. Feature: Compact dimensions (4.4 in height, 1.75 in width, 1.91 in depth) and light weight (0.2 lb). Benefit: Easier mounting in tight wall spaces and furniture applications, reducing wall strain. Application: Wall outlets, modular furniture, and accessory integration. Feature: Certifications and compliance (cULus Listed, NOM, W-C-596G). Benefit: Simplified procurement and risk management with recognized safety standards. Application: Projects requiring code-compliant, commercial-grade receptacles with broad compatibility.
Get a Quick Quote for a Eaton EZ6262CHBK
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton EZ6262CHBK?
Enquire Now
FAQs
The EZ6262CHBK is designed for modular decorator configurations. To install, align the receptacle with compatible EZLink modules and secure with standard wall or furniture mounting provisions. Wire the three conductors to a standard 15A, 125V circuit, ensuring proper ground. This modular approach minimizes field modifications and speeds up commissioning in office furniture and workstation projects.
The EZ6262CHBK is rated at 15A and 125 Vac, operating at 60 Hz with a three-wire configuration. It uses a NEMA 5-15R outlet, suitable for common office and equipment loads. The device is half controlled, supporting selective load management without a full switch, which helps reduce standby energy use in connected peripherals.
Yes. With its compact footprint, NEMA 5-15R compatibility, and modular EZLink design, this receptacle is ideal for office furniture, workstation modules, and equipment enclosures. Its half controlled feature enables targeted load management, while standard faceplate integration keeps installation straightforward and scalable across furniture lines.
This model carries cULus Listed, NOM, and Federal Specification W-C-596G certifications. These approvals confirm compliance with safety, performance, and procurement standards, reducing risk for national and federal projects and easing supplier qualification for commercial installations.
Using EZLink modular decorators reduces faceplate variation, minimizes wiring mistakes, and speeds deployment. The result is shorter project timelines, lower labor costs, and easier future upgrades, delivering measurable ROI in high-occupancy spaces like offices, classrooms, and healthcare facilities.
