Eaton EZ6362CDBK EZLink decorator receptacle - cULus
Part Number: EZ6362CDBK
Quick Summary
Eaton EZLink modular decorator receptacle is a compact, high-reliability outlet designed for control panels and enclosures. It reduces wiring complexity and enclosure density by delivering modular, dual controlled power at the point of use. Certified cULus Listed, NOM, and Federal Specification W-C-596G, it meets rigorous safety and compatibility requirements. With a robust NEMA 5-20R interface and a compact footprint, it supports reliable 20A, 125V performance in industrial environments.
Product Information
Extended Description
EZ6362CDBK Eaton: Eaton EZLink modular decorator receptacle, 20 A, 125 Vac, 60 Hz, dual controlled, NEMA 5-20R, three-wire, black
Product Name
Eaton EZLink modular decorator receptacle
Catalog Number
EZ6362CDBK
UPC
032664011245
Product Length/Depth
1.91 in
Product Height
4.4 in
Product Width
1.75 in
Product Weight
0.2 lb
Certifications
cULus Listed NOM Federal Specification Classification W-C-596G
Amperage Rating
20A
Voltage rating
125 Vac
Number of wires
3
Color
Black
Amperage and voltage ratings establish the core usability of EZ6362CDBK. With 20A at 125V and a three-wire configuration, it supports standard equipment loads while maintaining protection against overloads and short circuits. In practice, engineers can confidently power motors, drives, sensors, and control modules without bespoke adapters in tight panel spaces. Dual controlled design offers independent switching or control of circuits within a single decorator outlet. This capability reduces the need for separate devices, streamlines wiring diagrams, lowers panel footprint, and supports applications such as machine operator stations, safety interlocks, and local control points where two circuits must be run from a single location. Compact geometry features dimensions of 1.91 in depth, 4.4 in height, and 1.75 in width with a light 0.2 lb weight, enabling easy mounting in crowded enclosures. Installers benefit from minimal panel cutouts and simplified handling, which translates to faster commissioning and less service downtime. EZLink modular compatibility enables plug-and-play expansion with other modular devices in Eaton’s family. This approach reduces wiring errors, shortens commissioning times, and supports scalable growth across automation architectures. Certification coverage provides business value; cULus Listed, NOM, and Federal Specification W-C-596G demonstrate safety, reliability, and supplier qualification for regulated industries, reducing risk in projects and maintenance planning.
Get a Quick Quote for a Eaton EZ6362CDBK
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton EZ6362CDBK?
Enquire Now
FAQs
Install by placing the receptacle in a compatible panel opening and securing with the supplied mounting hardware. Connect the three wires to the hot, neutral, and ground terminals per the NEMA 5-20R configuration, ensuring proper strain relief and routing for dual controlled operation. Verify de-energization before wiring, then test polarity and fit before applying power.
Key specs include a 20A amperage rating, 125V voltage rating, NEMA 5-20R receptacle, three wires, and black color. It supports dual controlled operation and carries cULus Listing, NOM, and W-C-596G compliance. The compact depth of 1.91 inches, height of 4.4 inches, and width of 1.75 inches optimize panel space while preserving electrical performance.
Yes. With a 20A/125V rating, cULus listing, NOM, and W-C-596G compliance, it meets common industrial requirements. The dual controlled capability provides flexible control schemes, making it suitable for operator stations, safety interlocks, and compact control panels where space is at a premium.
The EZ6362CDBK carries cULus Listing, NOM, and Federal Specification W-C-596G, signaling safety, reliability, and regulatory alignment in North American markets. These certifications facilitate procurement, reduce project risk, and support faster approvals for regulated facilities across manufacturing and facilities operations.
Using this modular decorator receptacle reduces wiring errors, speeds installation, and simplifies panel upgrades thanks to EZLink compatibility. The strong certifications and compact form factor support long-term maintenance, predictable spare parts availability, and scalable expansion across production lines, delivering lower total cost of ownership in automated facilities.
