Eaton EZ6362CDLA EZLink modular decorator receptacle - cULus Listed
Part Number: EZ6362CDLA
Quick Summary
The Eaton EZ6362CDLA EZLink modular decorator receptacle delivers reliable power distribution for small control panels and workstations. Wiring diversity and rigid OEM layouts often slow installations and complicate maintenance. It carries cULus Listed status, NOM certification, and Federal Specification W-C-596G, supporting compliance across regulated facilities. With a compact footprint and 20A, 125Vac capability, it enables safer, faster wiring and easier future reconfiguration. Designed for NEMA 5-20R three-wire configurations, it's color-matched in light almond for code-compliant installations.
Product Information
Extended Description
EZ6362CDLA Eaton: Eaton EZLink modular decorator receptacle, 20 A, 125 Vac, 60 Hz, dual controlled, NEMA 5-20R, three-wire, light almond
Product Name
Eaton EZLink modular decorator receptacle
Catalog Number
EZ6362CDLA
UPC
032664012259
Product Length/Depth
1.91 in
Product Height
4.4 in
Product Width
1.75 in
Product Weight
0.2 lb
Certifications
cULus Listed NOM Federal Specification Classification W-C-596G
Amperage Rating
20A
Voltage rating
125 Vac
Number of wires
3
Color
Light Almond
Feature: 20A, 125Vac, 3 wires, NEMA 5-20R, dual controlled. Business Impact: Supports standard loads with flexible control options, reducing energy waste and simplifying panel wiring. Application: Ideal for control panels and workstation outlets in industrial environments. Feature: Compact footprint—1.91 in depth, 4.4 in height, 1.75 in width. Business Impact: Fits tight enclosures, lowers panel depth requirements, improves airflow, and speeds retrofit projects. Application: Instrument enclosures and compact automation panels. Feature: Light almond color. Business Impact: Improves visual identification and compliance with color-coding conventions in busy assemblies. Application: Commercial and manufacturing installations where quick recognition matters. Feature: Certifications—cULus Listed, NOM, Federal Specification W-C-596G. Business Impact: Supports regulatory compliance, safer operation, and easier inspections. Application: Regulated facilities such as industrial plants and healthcare environments. Feature: EZLink modular compatibility. Business Impact: Enables scalable panel designs and a straightforward upgrade path with existing modular devices. Application: Modular device ecosystems and future expansion projects in automation environments.
Get a Quick Quote for a Eaton EZ6362CDLA
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton EZ6362CDLA?
Enquire Now
FAQs
When installing EZ6362CDLA, verify it fits the existing modular device footprint and uses a NEMA 5-20R receptacle for three-wire, 125 VAC circuits. The compact 1.91 in depth helps with tight panel spaces, while the 4.4 in height and 1.75 in width ensure compatibility with standard faceplates. Follow NEC guidelines for wiring, and leverage the dual controlled feature to separate critical circuits for safety and energy management.
The EZ6362CDLA is rated for 20A at 125 VAC, three-wire configuration, with dual controlled outlets. This rating supports typical control-panel and workstation loads while maintaining a healthy safety margin for fused or breaker-protected circuits. Use appropriate gauge conductors and proper termination to maintain compliance and prevent overheating in continuous duty applications.
Yes, the EZ6362CDLA is appropriate for many industrial control panels and commercial installations requiring reliable power delivery. Its NEMA 5-20R configuration and dual controlled outlets support flexible power distribution. However, verify your facility’s specific code, environmental ratings, and termination requirements to ensure full suitability for data-center environments or mission-critical control rooms.
EZ6362CDLA carries cULus Listed status, is NOM certified, and aligns with Federal Specification W-C-596G. These certifications support regulatory compliance, safety evaluation, and standardized performance in regulated facilities. Always reference the product sheet and the listed certifications when completing vendor qualification and commissioning documentation.
The modular EZLink design reduces wiring errors and simplifies future upgrades, saving installation time and labor costs. Its lightweight construction (0.2 lb) and compact dimensions ease field modifications, while dual controlled functionality supports energy management and reduces nuisance power consumption. Over time, this translates to lower maintenance overhead and a faster return on investment when expanding or reconfiguring electrical panels.
