Eaton EZ6362CHRD Modular Decorator Receptacle - cULus
Part Number: EZ6362CHRD
Quick Summary
EZ6362CHRD is a modular decorator receptacle delivering reliable 20A, 125 Vac power for commercial outlets. Common panel and wiring mismatches cause downtime; modular EZLink devices streamline replacement and reduce field errors. This unit is cULus Listed and NOM certified, with Federal Specification W-C-596G, supporting compliance across facilities. Color coding in red helps ID at-a-glance in busy environments, while compact dimensions simplify retrofits and panel layouts. This combination of 20A, 125 Vac capability, and modular EZLink compatibility delivers faster installs, easier maintenance, and safer power distribution across commercial and light industrial sites. Compatible with standard 1-gang or modular electrical boxes, it supports quick field replacements and reduces total cost of ownership.
Product Information
Extended Description
EZ6362CHRD Eaton: Eaton EZLink modular decorator receptacle, 20 A, 125 Vac, 60 Hz, half controlled, NEMA 5-20R, three-wire, red
Product Name
Eaton EZLink modular decorator receptacle
Catalog Number
EZ6362CHRD
UPC
032664009693
Product Length/Depth
1.91 in
Product Height
4.4 in
Product Width
1.75 in
Product Weight
0.2 lb
Certifications
cULus Listed NOM Federal Specification Classification W-C-596G
Amperage Rating
20A
Voltage rating
125 Vac
Number of wires
3
Color
Red
Feature: 20A, 125 Vac, NEMA 5-20R three-wire, red decorator receptacle. Business Impact: Delivers robust, code-compliant power for critical outlets with clear visual identification, reducing mis-wiring and downtime. Application: Office and lab benches, control panels, and light industrial workstations. Feature: EZLink modular compatibility. Business Impact: Accelerates installation, simplifies wiring schemes, and lowers labor costs through standardized modular devices. Application: New builds and retrofit projects with modular power distribution. Feature: Red color coding. Business Impact: Improves safety and fast recognition in busy environments, minimizing cross-connection risk. Application: High-traffic electrical rooms and shared work areas. Feature: Certifications and compliance. Business Impact: Ensures regulatory alignment (cULus, NOM, W-C-596G) for facilities and audits. Application: Industrial facilities seeking formal compliance. Feature: Compact dimensions and light weight (1.91 in depth, 4.4 in height, 1.75 in width, 0.2 lb). Business Impact: Facilitates fit in tight spaces and quick reselection during maintenance. Application: Retrofit inserts behind furniture, in panel risers, or compact outlets. Feature: NEMA 5-20R, three-wire grounding. Business Impact: Safe, reliable power connections for shared circuits. Application: Commercial outlets, server rooms, and instrument panels.
Get a Quick Quote for a Eaton EZ6362CHRD
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton EZ6362CHRD?
Enquire Now
FAQs
To install EZ6362CHRD, connect a 20A, 125 Vac circuit to the hot and neutral terminals, ensure proper grounding, and secure the receptacle in a standard 1-gang or modular box. Verify three-wire configuration and correct polarity. The EZLink compatibility enables streamlined wiring, reducing installation time and potential field wiring errors. Ensure use in accordance with local codes and the cULus NOM listings.
Yes. EZ6362CHRD is designed for standard 1-gang or modular electrical boxes commonly used in commercial installations. Its compact dimensions—1.91 in depth, 4.4 in height, and 1.75 in width—facilitate retrofits in tight spaces. When mounting, follow manufacturer guidelines for secure attachment and maintain proper clearances for safe operation and serviceability.
EZ6362CHRD is cULus Listed and NOM certified, with Federal Specification W-C-596G. These certifications support regulatory compliance across facilities, simplify inspection processes, and help validate safety and performance expectations for electrical outlets in commercial and light industrial environments.
The receptacle provides 20A at 125 Vac with a NEMA 5-20R three-wire configuration, and its red color aids safety coding. The cULus/NOM/W-C-596G certifications further reinforce compliance. In critical loads, this translates to reliable power delivery, clear identification to prevent misconnection, and predictable performance during peak demand, supported by EZLink modular installation.
Common retrofit scenarios include upgrading existing outlets to modular decorator receptacles in laboratories, offices, and control panels to improve accessibility and safety. EZLink compatibility reduces wiring complexity, decreasing project duration and labor costs. The red color helps quick identification during maintenance, while the robust 20A, 125V rating supports a wide range of equipment without compromising safety.
