Eaton EZ6362SCB EZLink modular decorator receptacle - NEMA 5-20R
Part Number: EZ6362SCB
Quick Summary
The EZLink modular decorator receptacle from Eaton delivers reliable 20 A, 125 V outlets for commercial and industrial wiring projects. Engineers often grapple with tight spaces and complex panel layouts, making installation time and error-prone wiring a real cost driver. This model carries cULus Listed, NOM, and Federal Specification W-C-596G certifications, providing regulatory peace of mind across facilities. By leveraging the EZLink modular framework, it enables faster wiring, easier future expansions, and consistent performance in demanding environments, while the brown finish helps match standard electrical décor in reinforced enclosures. In short, it combines dependable electrical specs with practical, field-proven installability for value-driven projects and ongoing maintenance savings.
Product Information
Extended Description
EZ6362SCB Eaton: Eaton EZLink modular decorator receptacle, 20 A, 125 Vac, 60 Hz, split control, NEMA 5-20R, three-wire, brown
Product Name
Eaton EZLink modular decorator receptacle
Catalog Number
EZ6362SCB
UPC
032664009754
Product Length/Depth
1.91 in
Product Height
4.4 in
Product Width
1.75 in
Product Weight
0.2 lb
Certifications
cULus Listed NOM Federal Specification Classification W-C-596G
Amperage Rating
20A
Voltage rating
125 Vac
Number of wires
3
Color
Brown
Feature → Business Impact → Application. The EZ6362SCB delivers 20 A at 125 Vac with a NEMA 5-20R, three-wire configuration in a compact brown decorator receptacle, reducing panel footprint while maintaining safe, code-compliant power distribution for machines and enclosures. This enhances installation speed and lowers field wiring errors, particularly in dense control panels and switchgear cabinets where space is at a premium. Application-wise, it supports 60 Hz operation in commercial facilities and manufacturing lines, offering a reliable outlet solution for toolovers and PLC panels where quick access to power is critical. The split control capability enables flexible wiring schemes, which translate to lower commissioning time and easier fault isolation in complex automation layouts. Color and form-factor improvements also aid in standardized panel aesthetics and consistent maintenance visuals. Compatibility with EZLink modular devices accelerates updates and serviceability, delivering measurable lifecycle value.
Get a Quick Quote for a Eaton EZ6362SCB
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton EZ6362SCB?
Enquire Now
FAQs
EZ6362SCB is designed to work within the Eaton EZLink modular ecosystem, providing a reliable 20 A, 125 V decorator receptacle in a 3-wire configuration. Its NEMA 5-20R outlet enables straightforward wiring within modular device layouts, allowing technicians to extend or reconfigure outlets without rewriting large portions of the enclosure wiring. The result is faster panel builds and easier future expansions, with predictable electrical performance during machine cycles and procurement planning.
The EZ6362SCB is rated for 20 A, 125 Vac, at 60 Hz, with a 3-wire configuration and a NEMA 5-20R outlet. Its compact footprint (1.91 in depth, 4.4 in height, 1.75 in width) supports dense panel layouts, while the brown finish provides a consistent visual match for standard electrical installations. These specs help ensure compatibility with typical industrial receptacle circuits and simplify panel design calculations.
Yes. With NEMA 5-20R compatibility, three-wire wiring, and a robust 20 A rating, EZ6362SCB is well-suited for control panels and machinery enclosures in manufacturing environments. Its split control option and modular EZLink framework support efficient wiring strategies, reducing commissioning time and facilitating future upgrades. The component’s compact size also helps maximize usable space in crowded electrical cabinets.
EZ6362SCB carries cULus Listed, NOM, and Federal Specification Classification W-C-596G certifications. These approvals verify product safety, reliability, and compliance with regulatory requirements across facilities, streamlining procurement for regulated industries and reducing qualification time for new buildouts or retrofits.
The receptacle’s modular EZLink design simplifies replacement and upgrades, minimizing field labor during maintenance. Its compact form and standardized NEMA configuration reduce mismatch errors during service, lowering downtime costs. Combined with strong certifications and predictable electrical performance, EZ6362SCB supports faster project delivery, lower inventory complexity, and improved lifecycle cost management in automation and electrical infrastructure projects.
