Eaton EZTR5262CDB EZLink duplex receptacle - cULus
Part Number: EZTR5262CDB
Quick Summary
The Eaton EZLink modular duplex receptacle provides 15A, 125V power for control panels and workstations. It addresses tamper resistance and wiring complexity that slow installations in tight electrical enclosures. Certified as cULus Listed and NOM under Federal Specification Classification W-C-596G, ensuring compliance in diverse markets. With NEMA 5-15R compatibility and tamper-resistant design, it supports safe, code-compliant 125 Vac circuits and lowers field callbacks. For OEMs and integrators, its compact footprint speeds panel design and simplifies stocking, while its 15 A/125 Vac rating supports standard equipment infrastructure. This combination enhances reliability, reduces total cost of ownership, and accelerates time-to-value for industrial projects.
Product Information
Extended Description
EZTR5262CDB Eaton: Eaton EZLink modular duplex receptacle, 15 A, 125 Vac, 60 Hz, tamper-resistant, dual controlled, NEMA 5-15R, three-wire, brown
Product Name
Eaton EZLink modular duplex receptacle
Catalog Number
EZTR5262CDB
UPC
032664010194
Product Length/Depth
1.91 in
Product Height
4.4 in
Product Width
1.75 in
Product Weight
0.22 lb
Certifications
cULus Listed NOM Federal Specification Classification W-C-596G
Amperage Rating
15A
Voltage rating
125 Vac
Number of wires
3
Color
Brown
Feature: Tamper-resistant, NEMA 5-15R receptacle design. Benefit: Reduces shock risk and supports code compliance for 125 Vac circuits. Application: Safe, reliable outlets in control panels and machine enclosures. Feature: Modular EZLink integration. Benefit: Speeds installation in tight spaces and reduces wiring errors. Application: Panel wiring in manufacturing lines and compact electrical cabinets. Feature: Electrical specs of 15A at 125V, 60 Hz. Benefit: Supports standard industrial equipment without rewiring or custom power solutions. Application: Power distribution blocks and control circuits in automation assemblies. Feature: Compact dimensions (1.91 in depth, 1.75 in width). Benefit: Enables closer panel density and easier cable routing. Application: Dense control panels and compact electrical enclosures. Feature: Certifications including cULus Listed, NOM, and Federal Spec W-C-596G. Benefit: Simplifies procurement, audits, and supplier qualification. Application: Projects with strict regulatory requirements and multinational deployments.
Get a Quick Quote for a Eaton EZTR5262CDB
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton EZTR5262CDB?
Enquire Now
FAQs
EZTR5262CDB is a 15A, 125V, 60 Hz NEMA 5-15R receptacle with three wires and tamper-resistant features. It fits standard modular wiring device panels and is designed for straightforward mounting in control cabinets. When planning installations, ensure panel clearance, proper wiring with a three-wire setup, and matching enclosure ratings to maintain code compliance.
Key specs include a 15A amperage rating, 125V operating voltage, 60 Hz frequency, three-wire configuration, and a NEMA 5-15R receptacle. The brown device aligns with typical industrial color coding, and its tamper-resistant construction enhances safety in active work environments.
Yes. Its modular EZLink design, tamper-resistant NEMA 5-15R receptacle, and 15A/125V rating make it appropriate for control panels, machine housings, and other panel-mounted power solutions in industrial settings. The compact footprint also helps when panel real estate is constrained.
The receptacle is cULus Listed and NOM certified, with Federal Specification W-C-596G classification. These certifications support regulatory compliance across North American markets and simplify procurement and supplier qualification for regulated environments.
Adopting EZLink modular receptacles reduces installation time due to a streamlined wiring approach, lowers field labor costs, and minimizes wiring errors. The tamper-resistant, durable design also reduces maintenance calls and improves panel reliability, contributing to lower total cost of ownership over the equipment lifecycle.
