Eaton EZTR6262CDLA EZLink decorator receptacle - NEMA 5-15R
Part Number: EZTR6262CDLA
Quick Summary
The Eaton EZLink modular decorator receptacle is a versatile 15 A, 125 Vac outlet solution for commercial installations. Users often struggle to find outlets that blend into décor while delivering reliable safety and quick service in busy work environments. This model carries cULus Listed, NOM compliance, and Federal Specification W-C-596G, providing strong regulatory alignment and robust construction. By standardizing on EZLink, facilities gain consistent aesthetics and faster retrofits, reducing unscheduled downtime and supplier variation. In addition to decorative appeal, it supports modular wiring strategies for efficient procurement and scalable deployment across offices, labs, and light-industrial spaces. This combination supports safer work environments and faster project turnover, a clear business value.
Product Information
Extended Description
EZTR6262CDLA Eaton: Eaton EZLink modular decorator receptacle, 15 A, 125 Vac, 60 Hz, tamper-resistant, dual controlled, NEMA 5-15R, three-wire, light almond
Product Name
Eaton EZLink modular decorator receptacle
Catalog Number
EZTR6262CDLA
UPC
032664011696
Product Length/Depth
1.91 in
Product Height
4.4 in
Product Width
1.75 in
Product Weight
0.22 lb
Certifications
cULus Listed NOM Federal Specification Classification W-C-596G
Amperage Rating
15A
Voltage rating
125 Vac
Number of wires
3
Color
Light Almond
Feature: 15A, 125V, three-wire NEMA 5-15R outlet provides familiar, reliable power for everyday equipment. Business Impact: Standard hardware reduces compatibility issues with printers, displays, and peripherals while maintaining level field reliability. Application: Offices, classrooms, and light-industrial spaces where wall-mounted outlets must disappear into décor without compromising performance. Feature: Tamper-resistant design enhances safety in high-traffic areas. Business Impact: Minimizes child and incidental contact, reducing incident reports and warranty claims. Application: Hallways, lobbies, reception areas, and educational facilities demanding compliant outlets. Feature: EZLink modular decorator receptacle design enables rapid upgrades and scalable installations. Business Impact: Streamlines procurement, reduces labor time, and supports mixed-device configurations. Application: Retrofit projects and new-builds requiring consistent modular device compatibility. Feature: Light almond finish and compact dimensions deliver aesthetic compatibility with standard wall finishes. Business Impact: Improves user satisfaction and reduces need for additional trim or repaint during installs. Application: Corporate offices, hospitality fronts, and labs seeking a clean, professional look. Feature: Regulatory alignment through cULus, NOM, and W-C-596G certifications. Business Impact: Enhances audit readiness and code compliance, minimizing risk during inspections. Application: Facilities across North America with strict electrical standards. Feature: Overall lifecycle efficiency with standardized EZLink components. Business Impact: Lowers SKU proliferation, simplifies maintenance planning, and speeds deployment. Application: Large facilities and multi-site rollouts across offices and campuses.
Get a Quick Quote for a Eaton EZTR6262CDLA
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton EZTR6262CDLA?
Enquire Now
FAQs
Power must be off before any work. Use a compatible wall box and secure the decorator receptacle to the device mounting yoke. Connect the hot conductor to the brass terminal, neutral to the silver terminal, and ground to the green grounding screw. Ensure the tamper-resistant shutters are clean and test with a circuit analyzer after wiring. Follow NEC and local codes for box fill and mounting depth. This approach minimizes miswiring risks and supports reliable operation in busy environments.
Yes. The EZTR6262CDLA is part of Eaton’s EZLink modular ecosystem, designed to pair with compatible modular decorator devices and faceplates. This compatibility enables scalable, uniform outlet configurations across renovations or new builds. By using a common module family, procurement is simplified, stock is reduced, and installer training is streamlined, which shortens project timelines in commercial interiors.
The receptacle is rated for 15A at 125V with 60 Hz operation and uses a 3-wire connection for hot, neutral, and ground. It is a NEMA 5-15R configuration, designed for standard branch circuits in office and light-industrial environments. This specification set supports typical office equipment and ensures broad compatibility with standard power distribution systems while meeting common code requirements.
EZTR6262CDLA is cULus Listed and NOM compliant, with Federal Specification W-C-596G recognition. These certifications indicate conformance to UL electrical safety standards and U.S. regulatory requirements, aiding inspection readiness and reducing the risk of non-compliance during audits. The combination supports safer installations in commercial spaces and simplifies contractor approvals.
Standardizing on the EZLink decorator receptacle streamlines procurement with a consistent component family, reducing SKU counts and inventory complexity. Faster installation, fewer field errors, and fewer returns due to misfit parts translate to lower labor costs and shortened project cycles. Over time, maintenance planning improves as replacements align with a single modular ecosystem, delivering predictable lifecycle costs.
