Eaton EZTR6362CDLA Decorator Receptacle - NEMA 5-20R
Part Number: EZTR6362CDLA
Quick Summary
Eaton EZTR6362CDLA decorator receptacle is a modular power outlet designed for fast, reliable wiring in commercial and industrial control panels. Engineers and installers often contend with installation complexity and safety concerns in busy equipment spaces. It carries cULus listing and NOM compliance under Federal Specification W-C-596G, supporting safe operation and procurement acceptance. With a 20A, 125 VAC rating and NEMA 5-20R configuration, the EZLink module speeds wiring while delivering durable power in dense panel racks. The light almond finish blends with standard panel aesthetics, and the modular EZLink design enables scalable expansion for future installations. This combination reduces commissioning time and minimizes field errors, delivering measurable savings in maintenance, downtime, and overall project cost. Secondary benefits include compatibility with modular power strategies and robust safety features.
Product Information
Extended Description
EZTR6362CDLA Eaton: Eaton EZLink modular decorator receptacle, 20 A, 125 Vac, 60 Hz, tamper-resistant, dual controlled, NEMA 5-20R, three-wire, light almond
Product Name
Eaton EZLink modular decorator receptacle
Catalog Number
EZTR6362CDLA
UPC
032664011993
Product Length/Depth
1.91 in
Product Height
4.4 in
Product Width
1.75 in
Product Weight
0.22 lb
Certifications
cULus Listed NOM Federal Specification Classification W-C-596G
Amperage Rating
20A
Voltage rating
125 Vac
Number of wires
3
Color
Light Almond
Feature: 20A, 125 VAC, NEMA 5-20R, three-wire configuration with tamper-resistant design. Business Impact: Delivers safe, code-compliant power with reduced risk of arcing or accidental contact, speeding approvals and commissioning. Application: Ideal for industrial control panels, machine enclosures, and shared workstations where reliable outlets are essential.Feature: EZLink modular decorator design for rapid field installation. Business Impact: Cuts wiring time, minimizes miswiring, and lowers labor costs. Application: Retrofit projects and new equipment in data centers, manufacturing lines, and packaging machinery.Feature: Dual controlled capability. Business Impact: Enables coordinated control across circuits; improves monitoring and safety in multi-circuit layouts. Application: Panels requiring independent control of outlets or grouped control for start/stop sequences.Feature: Tamper-resistant feature. Business Impact: Reduces tampering risk in high-traffic installations and meets safety code requirements. Application: Public-access equipment, lab benches, and point-of-use stations.Feature: Light Almond color and compact dimensions (1.91 in depth, 4.4 in height, 1.75 in width) with 0.22 lb weight. Business Impact: Space-efficient form factor fits standard decorator boxes and enclosures. Application: Cabinet interiors, electrical closets, and panel upgrades where space is at a premium.Feature: Certifications and compliance (cULus Listed, NOM, W-C-596G). Business Impact: Simplifies procurement and job-site compliance for regulated installs. Application: North American facilities requiring recognized safety and performance standards.
Get a Quick Quote for a Eaton EZTR6362CDLA
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton EZTR6362CDLA?
Enquire Now
FAQs
Yes. EZTR6362CDLA is designed for standard decorator box installations in panel enclosures and wall-mounted setups. Use the EZLink modular approach: mount the frame, connect the three wires (hot, neutral, ground), and snap the receptacle into place. Its compact depth and light weight simplify retrofits and minimize downtime in crowded electrical spaces.
The receptacle delivers 20A at 125 VAC with a NEMA 5-20R three-wire configuration. It is tamper-resistant and carries cULus listing and NOM compliance under W-C-596G. Together these features support code-compliant power distribution, reduce shock hazards, and streamline procurement for North American facilities.
Dual controlled capability enables coordinated control across circuits, improving monitoring and safety in multi-circuit layouts. In practice, this supports simplified start/stop sequences and centralized control strategies in automated panels, reducing wiring complexity and the likelihood of miswired connections during commissioning.
Yes. The EZTR6362CDLA is finished in Light Almond to align with common panel aesthetics. This color choice helps minimize visual disruption in exposed or semi-enclosed electrical installations, facilitating cleaner, professional-looking panel interiors and easier post-installation inspections.
Expect noticeable time savings during initial wiring and commissioning due to the EZLink modular design, plus reduced field errors from tamper-resistant safety features. Over the life of the installation, these improvements translate to lower labor costs, faster uptime for critical equipment, and a favorable return on investment for controlled electrical environments.
