Eaton FAZ-Z25/1 Supplementary Protector - UL 1077
Part Number: FAZ-Z25/1
Quick Summary
The Eaton FAZ-Z25/1 supplementary protector is a 25 A UL 1077 listed device designed to guard sensitive loads in industrial control panels and machinery. This compact, single-pole protector helps prevent nuisance trips that disrupt production, addressing common panel protection pain points. It carries key standards such as IEC 60947-2, UL 1077, and CSA Std. C22.2 No.235, reinforcing compliance across international facilities. With standard terminals and a small footprint, it delivers reliable protection while simplifying installation and ongoing maintenance, making it a practical choice for engineers seeking robust, ready-to-specification components in wiring and connectivity applications.
Product Information
Extended Description
FAZ-Z25/1 Eaton: Eaton FAZ supplementary protector,UL 1077 Industrial miniature circuit breaker - supplementary protector,25 A,15 kAIC,Single-pole,240/415 V,2-3X /n,Standard terminals,Z Curve
Product Name
Eaton FAZ supplementary protector
Catalog Number
FAZ-Z25/1
EAN
4015082786281
Product Length/Depth
1 in
Product Height
1 in
Product Width
0.75 in
Product Weight
0.5 lb
Warranty
1 year
Certifications
IEC 60947-2 UL 1077 CSA Std. C22.2 No.235
Catalog Notes
Very low instantaneous setting to provide tighter protection for loads more sensitive to overcurrents.
Number of poles
Single-pole
Terminals
Standard
Amperage Rating
25 A
Trip Type
2-3X /n
Feature: 25 A amperage rating provides solid protection for typical control circuits. Business impact: minimizes nuisance trips and equipment wear, reducing downtime and maintenance costs. Application: control panels and machine enclosures handling moderate industrial loads. Feature: 2-3X instantaneous trip characteristic offers tighter protection for sensitive loads. Business impact: prevents short-duration overloads from causing damage, extending equipment life. Application: motors, sensors, and control electronics subject to overcurrents. Feature: UL 1077, IEC 60947-2, and CSA certification ensure compliance across regions. Business impact: simplifies regulatory adherence and supplier consolidation for international projects. Application: global manufacturing lines and multi-site installations. Feature: compact footprint with standard terminals simplifies retrofits and panel layouts. Business impact: saves panel space, enables faster commissioning, and reduces wiring complexity. Application: retrofit projects and new equipment in space-constrained enclosures. Feature: 1-year warranty and Eaton brand reliability provide long-term support. Business impact: lowers risk and improves total cost of ownership. Application: ongoing service contracts and maintenance planning.
Get a Quick Quote for a Eaton FAZ-Z25/1
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton FAZ-Z25/1?
Enquire Now
FAQs
The FAZ-Z25/1 is designed for standard wiring with Eaton's compatible single-pole protection in control panels and industrial enclosures. It uses standard terminals and fits in space-constrained panels of 240/415 V systems. Ideal for retrofit projects or new installations where compact protection and easy integration with existing MCBs are required.
This unit offers a 25 A amperage rating and a 2-3X instantaneous trip characteristic to curb fast overcurrents. It complies with IEC 60947-2, UL 1077, and CSA Std. C22.2 No.235, delivering reliable short-circuit protection for sensitive loads while minimizing nuisance trips in demanding industrial environments.
Yes. The FAZ-Z25/1 is specified for 240/415 V systems, single-pole operation, and standard terminals. Its compact footprint and robust certification make it suitable for control panels and equipment wiring in diverse industrial settings where tight overcurrent protection is required without complicating the wiring scheme.
The protector carries IEC 60947-2, UL 1077, and CSA Std. C22.2 No.235 certifications. These align with global electrical safety and performance requirements, enabling cross-border procurement, easier audit readiness, and smoother regulatory approval for machinery and panel assemblies in multinational facilities.
By reducing nuisance trips and protecting sensitive components, FAZ-Z25/1 lowers unplanned downtime and extends equipment life. Its compact form factor simplifies installation and servicing in tight panels, and the 1-year warranty provides an additional layer of risk mitigation for procurement and maintenance teams.
