Eaton FAZ-Z25/3 supplementary protector - UL 1077
Part Number: FAZ-Z25/3
Quick Summary
Eaton FAZ-Z25/3 supplementary protector protects sensitive loads in control panels from nuisance overloads. Engineers often struggle with trips driven by small overcurrents that halt production. This device delivers a very low instantaneous setting, enabling tighter protection. Certified to IEC 60947-2, CSA Std. C22.2 No.235, and UL 1077, it aligns with modern safety and compliance expectations. In practice, the three-pole design with standard terminals supports quick retrofits and reliable three-phase protection for industrial machinery. With a 1-year warranty and compact 3-in footprint, it simplifies stocking, maintenance intervals, and installation in tight panels. Compliance-ready protection translates to lower audit risk and fewer field failures, supporting uptime and total cost of ownership.
Product Information
Extended Description
FAZ-Z25/3 Eaton: Eaton FAZ supplementary protector,UL 1077 Industrial miniature circuit breaker - supplementary protector,25 A,15 kAIC,Three-pole,2-3X /n,Standard terminals,Z Curve
Product Name
Eaton FAZ supplementary protector
Catalog Number
FAZ-Z25/3
EAN
4015082789299
Product Length/Depth
3 in
Product Height
3 in
Product Width
3 in
Product Weight
1 lb
Warranty
1 year
Certifications
IEC 60947-2 CSA Std. C22.2 No.235 UL 1077
Catalog Notes
Very low instantaneous setting to provide tighter protection for loads more sensitive to overcurrents.
Number of poles
Three-pole
Terminals
Standard
Amperage Rating
25 A
Trip Type
2-3X /n
With a 25 A, 15 kAIC protection rating, the FAZ-Z25/3 delivers reliable short-circuit and overload protection. Business impact: guards against damaging events and reduces unplanned downtime on critical lines. Application: ideal for three-phase control panels and motor circuits in automated manufacturing environments. Very low instantaneous setting provides tighter protection for loads more sensitive to overcurrents. Business impact: minimizes nuisance trips and process interruptions, boosting overall equipment reliability. Application: suitable for sensitive automation circuits, CNCs, and robotics systems where precision protection matters. Three-pole design with standard terminals enables quick retrofits and straightforward installation in existing enclosures. Business impact: lowers retrofit time and maintenance costs while ensuring robust three-phase protection. Application: convenient in retrofit projects or new builds with standard terminal footprints in control cabinets. Compact 3x3x3 inch footprint and 1 lb weight deliver space savings and easier handling. Business impact: improves panel density and reduces shipping and installation effort. Application: ideal for crowded electrical enclosures in industrial settings. Certifications IEC 60947-2, CSA C22.2 No.235, UL 1077 provide regulatory assurance. Business impact: supports compliance audits and safety qualifications with minimal design changes. Application: suitable for regulated industrial installations across North America. Warranty of 1 year adds peace of mind for service and maintenance planning. Business impact: lowers total cost of ownership through predictable coverage and dependable replacement timelines. Application: long-term reliability for manufacturing lines and machine tools.
Get a Quick Quote for a Eaton FAZ-Z25/3
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton FAZ-Z25/3?
Enquire Now
FAQs
FAZ-Z25/3 provides a three-pole design with standard terminals, enabling easy retrofit in existing enclosures. It is compatible with typical control panels and industrial machines that require reliable supplementary protection. The device is designed for three-phase circuits and aligns with IEC 60947-2 and UL 1077 standards, ensuring straightforward installation and regulatory compliance.
The unit is rated at 25 A with a 15 kAIC short-circuit rating. It features a low instantaneous setting to minimize nuisance trips on sensitive loads. The three-pole configuration provides robust three-phase protection, while standard terminals simplify wiring and field replacement in control cabinets and machines.
Yes. The three-pole FAZ-Z25/3 is specifically designed for 3-phase protection in industrial settings, including control panels, motor circuits, and automation equipment. Its compact footprint and standard terminals make it practical for retrofit into crowded enclosures without sacrificing protection performance.
FAZ-Z25/3 carries IEC 60947-2, CSA Std. C22.2 No.235, and UL 1077 certifications. These standards support safe operation, regulatory compliance, and alignment with common North American and international electrical installation requirements for supplementary protection devices.
A 1-year warranty reduces maintenance risk, while the compact 3x3x3 in, 1 lb footprint eases handling and installation. The very low instantaneous setting reduces downtime from nuisance trips, improving uptime and potentially lowering total cost of ownership by extending equipment life and simplifying spare parts stocking for control panels.
