Eaton FAZ-Z4/4 Supplementary Protector - UL 1077
Part Number: FAZ-Z4/4
Quick Summary
The Eaton FAZ-Z4/4 supplementary protector provides precise overcurrent protection for sensitive loads in electrical panels. Panel designers often wrestle with nuisance trips and inadequate protection when space is tight and wiring is dense. UL 1077, CSA, and IEC 60947-2 certifications validate the device for global manufacturing environments, while its Z Curve and very low instantaneous setting tighten protection. The four-pole architecture, standard terminals, and balanced 4 A rating simplify installation and reduce downtime in automation panels. The 15 kAIC withstand capability supports short-circuit resilience, helping OEMs meet performance targets without sacrificing footprint or serviceability.
Product Information
Extended Description
FAZ-Z4/4 Eaton: Eaton FAZ supplementary protector,UL 1077 Industrial miniature circuit breaker - supplementary protector,4 A,15 kAIC,Four-pole,2-3X /n,Standard terminals,Z Curve
Product Name
Eaton FAZ supplementary protector
Catalog Number
FAZ-Z4/4
EAN
4015082791117
Product Length/Depth
3 in
Product Height
3 in
Product Width
3 in
Product Weight
1 lb
Warranty
1 year
Certifications
CSA Std. C22.2 No.235 UL 1077 IEC 60947-2
Catalog Notes
Very low instantaneous setting to provide tighter protection for loads more sensitive to overcurrents.
Number of poles
Four-pole
Terminals
Standard
Amperage Rating
4 A
Trip Type
2-3X /n
Feature: Four-pole supplementary protector design enables complete multi-pole protection in three-phase systems. Benefit: Improves system reliability and protects downstream equipment from coordinated phase faults. Application: Panel boards and control cabinets in industrial automation. Outcome: Reduced downtime and safer, compliant operation. Feature: Very low instantaneous setting with Z Curve provides tighter protection for sensitive loads. Benefit: Minimizes nuisance trips and protects costly devices from immediate overcurrents. Application: Motor starters, precision drives, and delicate sensors. Outcome: Lower maintenance costs and improved uptime. Feature: Standard terminals and compact 3x3x3 in footprint simplify installation. Benefit: Easier wiring, faster panel assembly, and scalable upgrades. Application: Retrofit and new-build control panels in machinery. Outcome: Time savings and lower labor costs. Feature: 4 A amperage rating with 2-3X /n trip type delivers precise overload protection suitable for small-load circuits. Benefit: Tailored protection that avoids over-tripping small loads while maintaining safety margins. Application: Control circuits and auxiliary power supplies. Outcome: Enhanced protection with predictable performance. Feature: Certifications to CSA, UL 1077, and IEC 60947-2 ensure global compliance. Benefit: Simplifies cross-border approvals and supplier qualification. Application: OEMs supplying equipment to multiple markets. Outcome: Faster time-to-market and reduced compliance risk.
