Eaton FAZ-Z40/1 Supplementary Protector - UL 1077
Part Number: FAZ-Z40/1
Quick Summary
Eaton FAZ-Z40/1 supplementary protector delivers fast overcurrent protection for compact industrial control panels. Engineers often struggle with setting instantaneous trips that protect sensitive loads without triggering nuisance outages, leading to unplanned downtime. This device is certified to UL 1077, IEC 60947-2, and CSA Std. C22.2 No.235, helping you meet stringent safety and regulatory requirements across North America and beyond. With its single-pole design, standard terminals, and tight protective curve, it supports quick retrofits and reliable commissioning. By aligning precise protection with easy installation, it drives reduced maintenance costs, improved system availability, and better total cost of ownership in Wiring & Connectivity applications.
Product Information
Extended Description
FAZ-Z40/1 Eaton: Eaton FAZ supplementary protector,UL 1077 Industrial miniature circuit breaker - supplementary protector,40 A,15 kAIC,Single-pole,240/415 V,2-3X /n,Standard terminals,Z Curve
Product Name
Eaton FAZ supplementary protector
Catalog Number
FAZ-Z40/1
EAN
4015082786304
Product Length/Depth
1 in
Product Height
1 in
Product Width
0.75 in
Product Weight
0.5 lb
Warranty
1 year
Certifications
UL 1077 IEC 60947-2 CSA Std. C22.2 No.235
Catalog Notes
Very low instantaneous setting to provide tighter protection for loads more sensitive to overcurrents.
Number of poles
Single-pole
Terminals
Standard
Amperage Rating
40 A
Trip Type
2-3X /n
Feature → 1: Amperage rating and fault current handling. The FAZ-Z40/1 provides a 40 A rating with a 15 kAIC fault current capability, enabling reliable protection for standard control circuits without over‑tripping. Business impact: predictable protection margins reduce downtime and spare-part costs. Application: industrial control panels and machine wiring where short-circuit withstand is critical. Feature → 2: Very low instantaneous setting for sensitive loads. The catalog notes describe a very low instantaneous setting to provide tighter protection for loads that are more sensitive to overcurrents. Business impact: fewer nuisance trips preserve process continuity and equipment availability. Application: sensitive loads in packaging, robotics, and automation lines. Feature → 3: Trip type and performance curve. Configured as 2-3X /n, the FAZ-Z40/1 supports selective coordination with downstream devices, improving protection logic and reducing the blast radius of faults. Business impact: improved system selectivity and reduced repair time. Application: multi-device protection schemes in control cabinets. Feature → 4: Physical design for easy installation. With a 1 in length, 1 in height, and 0.75 in width footprint and standard terminals, this unit installs quickly in already-wired spaces and integrates with common DIN rail or panel layouts. Business impact: faster commissioning and lower labor costs. Application: retrofit projects and new panel builds in Wiring & Connectivity. Feature → 5: Certifications and warranty. UL 1077, IEC 60947-2, CSA Std. C22.2 No.235 certifications plus a 1-year warranty provide regulatory assurance and long-term product support. Business impact: reduced compliance risk and predictable maintenance budgeting. Application: North American and international automation environments.
Get a Quick Quote for a Eaton FAZ-Z40/1
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton FAZ-Z40/1?
Enquire Now
FAQs
FAZ-Z40/1 uses standard terminals and a compact single-pole form factor, making it easy to drop into most legacy or new panel designs. Its 1 x 1 x 0.75 in footprint helps preserve space in crowded enclosures, while the 240/415 V operating range aligns with common industrial power systems. Ensure conductor sizing matches 40 A protections and follow UL 1077 wiring guidelines for safe termination.
The device is rated 40 A with a 15 kAIC short-circuit capacity and features a 2-3X /n trip profile for effective selective protection. It is a single-pole supplementary protector suitable for 240/415 V circuits. These specs support tight overcurrent protection for sensitive loads while maintaining coordination with downstream devices.
Yes. FAZ-Z40/1 is designed for 240/415 V applications common in machine control panels and wiring networks. Its core strength is protecting control circuits from overcurrents while enabling straightforward wiring with standard terminals. For best results, pair it with downstream protection to ensure selectivity across the control system.
FAZ-Z40/1 carries UL 1077, IEC 60947-2, and CSA Std. C22.2 No.235 certifications, indicating compliance with recognized safety and performance requirements for supplementary protectors. This helps meet regulatory obligations in North America and international projects, easing procurement and system integration in automation and electrical installations.
By reducing nuisance trips with a low instantaneous setting and providing dependable 40 A protection, FAZ-Z40/1 minimizes unplanned downtime and maintenance visits. The 1-year warranty adds support confidence, while standard terminals shorten install time and improve overall reliability in Wiring & Connectivity applications.
