Eaton FAZ-Z40/4 Supplementary Protector - UL 1077
Part Number: FAZ-Z40/4
Quick Summary
The Eaton FAZ-Z40/4 supplementary protector provides fast overcurrent protection for sensitive loads in panelboards. Engineers often face nuisance trips and uneven protection during short overloads. UL 1077, IEC 60947-2, and CSA C22.2 No.235 certifications ensure global compliance for control panels and automation equipment. Designed for ease of installation with standard terminals, it delivers reliable protection for industrial wiring and control systems while helping reduce downtime and maintenance costs.
Product Information
Extended Description
FAZ-Z40/4 Eaton: Eaton FAZ supplementary protector,UL 1077 Industrial miniature circuit breaker - supplementary protector,40 A,15 kAIC,Four-pole,2-3X /n,Standard terminals,Z Curve
Product Name
Eaton FAZ supplementary protector
Catalog Number
FAZ-Z40/4
EAN
4015082791193
Product Length/Depth
3 in
Product Height
3 in
Product Width
3 in
Product Weight
1 lb
Warranty
1 year
Certifications
IEC 60947-2 CSA Std. C22.2 No.235 UL 1077
Catalog Notes
Very low instantaneous setting to provide tighter protection for loads more sensitive to overcurrents.
Number of poles
Four-pole
Terminals
Standard
Amperage Rating
40 A
Trip Type
2-3X /n
Feature: Four-pole construction with standard terminals provides complete four-wire protection for three-phase systems, aligning with the behavior of an industrial miniature circuit breaker. Business Impact: Improves fault isolation and simplifies wiring, reducing commissioning time, avoiding miswiring in complex panelboards and MCCs, and supporting safer start-up in automated lines. Application: Ideal for industrial wiring and connectivity in automation panels, motor control centers, and switchgear. Feature: 40 A rating with 15 kAIC breaking capacity offers robust short-circuit protection for feeders and motor loads. Business Impact: Reduces equipment damage risk, minimizes unplanned outages, and supports near-term reliability targets in manufacturing lines. Application: Suitable for control panels and panelboards in automation and machine-building environments. Feature: Very low instantaneous setting tightens protection against fast transients on sensitive loads like PLCs and servo drives. Business Impact: Minimizes nuisance trips while preserving fast response to genuine faults, improving process availability. Application: Critical control circuits and machine interfaces in CNC machines and robotics systems. Feature: Certifications including UL 1077, IEC 60947-2, and CSA C22.2 No.235 ensure regulatory compliance and international acceptance. Business Impact: Facilitates global procurement, simplifies audits, and reduces compliance risk for multinational projects. Application: Global manufacturing facilities and multi-site automation deployments. Feature: Compact 3 x 3 x 3 in footprint, 1 lb weight, and standard terminals enable easy installation and quick field swaps. Business Impact: Lowers labor costs, reduces spare-parts inventory, and accelerates maintenance cycles. Application: Panel cabinets, enclosures, and retrofit projects in existing systems. Feature: Trip Type 2-3X provides selective coordination with upstream protective devices. Business Impact: Enhances reliability by ensuring protective action occurs at the correct location, protecting critical loads without unnecessary downtime. Application: Large motor feeders and automated process lines requiring staged protection.
Get a Quick Quote for a Eaton FAZ-Z40/4
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton FAZ-Z40/4?
Enquire Now
FAQs
Install the four-pole device using standard terminals in a compatible panel or MCC, following the wiring diagram in the Eaton datasheet. Tighten terminations to recommended torque and ensure correct line-neutral connections. The 3 x 3 x 3 inch footprint supports straightforward field swaps and tidy wiring in industrial control cabinets.
The unit is rated at 40 A with a 15 kAIC breaking capacity, featuring four poles and a 2-3X instantaneous trip characteristic. UL 1077 certification confirms its role as a supplementary protector, while the ratings support reliable protection of feeders and motors in automation panels and factory equipment.
Yes. FAZ-Z40/4 is certified to IEC 60947-2, CSA C22.2 No.235, and UL 1077, ensuring compliance for control panels and automation equipment. These certifications support global deployment and simplify audits for multinational manufacturing sites.
The very low instantaneous setting provides tighter protection for loads that are sensitive to overcurrents, such as PLCs and servo drives, reducing nuisance trips. It preserves fast fault response for genuine faults, improving process availability without compromising safety.
FAZ-Z40/4 comes with a 1-year warranty and a compact 3 x 3 x 3 inch footprint, weighing 1 lb with standard terminals. This small form factor simplifies replacement, minimizes inventory, and supports rapid procurement for panel upgrades and retrofit projects.
