Eaton FAZ-Z50/2 Supplementary Protector - UL 1077
Part Number: FAZ-Z50/2
Quick Summary
Eaton FAZ-Z50/2 supplementary protector protects circuits in control panels and machines from overcurrent. This compact device helps engineers reduce nuisance trips and downtime by delivering precise short‑circuit protection where sensitive loads live. It carries UL 1077, CSA C22.2 No. 235, and IEC 60947-2 certifications, ensuring cross‑border compliance for industrial installations. Designed for Wiring & Connectivity applications, it complements existing protection schemes while supporting efficient panel layouts and standardized wiring. With its solid warranty and straightforward installation, it also supports predictable maintenance cycles and total cost of ownership improvements for automation projects.
Product Information
Extended Description
FAZ-Z50/2 Eaton: Eaton FAZ supplementary protector,UL 1077 Industrial miniature circuit breaker - supplementary protector,50 A,15 kAIC,Two-pole,2-3X /n,Standard terminals,Z Curve
Product Name
Eaton FAZ supplementary protector
Catalog Number
FAZ-Z50/2
EAN
4015082788308
Product Length/Depth
1.5 in
Product Height
1.5 in
Product Width
1.5 in
Product Weight
0.5 lb
Warranty
1 year
Certifications
UL 1077 CSA Std. C22.2 No.235 IEC 60947-2
Catalog Notes
Very low instantaneous setting to provide tighter protection for loads more sensitive to overcurrents.
Number of poles
Two-pole
Terminals
Standard
Amperage Rating
50 A
Trip Type
2-3X /n
Feature is UL 1077 supplementary protection with CSA and IEC certifications, delivering compliance and safety across regional standards. The business impact is reduced regulatory risk and fewer field failures, translating to fewer service calls on critical automation lines. This is ideal for control panels and machine guards where reliable protection is essential. Feature 50 A amperage rating in a two-pole configuration enables protection of moderate automation loads while maintaining service continuity, reducing unplanned downtime and enabling smoother startup sequences in conveyors and packaging lines. Feature very low instantaneous setting discussed in the catalog notes provides tighter protection for loads more sensitive to overcurrents, improving protection for servo drives and intelligent sensors while limiting nuisance trips. Feature standard terminals and a compact 1.5 in footprint simplify panel mounting and wiring, accelerating installation and improving maintainability for electrical technicians. Feature a 1-year warranty and Eaton reliability, ensuring lower total cost of ownership over the device lifecycle by minimizing replacement cycles and service costs. Feature multi‑certification coverage supports cross‑regional projects, reducing redesign risk for multinational automation deployments and speeding up procurement cycles for global rollouts.
Get a Quick Quote for a Eaton FAZ-Z50/2
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton FAZ-Z50/2?
Enquire Now
FAQs
When deploying the FAZ-Z50/2 in a control panel, follow the standard two-pole mounting approach and use the standard terminals to simplify wiring. Verify tray space and routing to avoid heat buildup, and torque terminals per manufacturer guidelines to maintain reliable contact. The compact 1.5 in footprint helps maximize usable panel area, enabling cleaner wire management and easier future expansion.
Key specs include a 50 A amperage rating, two-pole configuration, and a 15 kAIC short‑circuit current rating. These values suit medium‑load automation circuits in control panels and machines, providing reliable overcurrent protection while preserving continuity for non-faulted loads. The UL 1077, CSA, and IEC 60947-2 certifications ensure compliance across regions.
Yes. The catalog notes describe a very low instantaneous setting intended to tighten protection for loads more sensitive to overcurrents. This makes FAZ-Z50/2 well‑suited for servo drives, servo amplifiers, and precision sensors where nuisance trips can impact production throughput. Pairing this device with appropriate wiring and proper panel heat management ensures stable operation.
FAZ-Z50/2 is certified to UL 1077, CSA Std. C22.2 No.235, and IEC 60947-2. These certifications support regulatory compliance for North American and international installations. The multi‑certification profile reduces design wind‑back, accelerates procurement, and simplifies audit trails for safety and quality programs in industrial facilities.
The device’s 50 A rating and tight overcurrent protection help reduce nuisance trips, lowering unplanned downtime and maintenance disruptions. A compact form factor eases installation and future upgrades, while the 1-year warranty and Eaton reliability contribute to lower total cost of ownership by reducing replacement frequency and service interventions in busy automation environments.
