Eaton FAZ-Z50/4 supplementary protector - UL 1077
Part Number: FAZ-Z50/4
Quick Summary
Eaton FAZ-Z50/4 supplementary protector delivers fast overcurrent protection for industrial control panels. This solution helps prevent nuisance trips and reduces downtime by guarding sensitive loads against short circuits and overloads. Certifications include UL 1077, CSA Std. C22.2 No.235, and IEC 60947-2, ensuring robust compliance across diversified panels and international installations. The four-pole design with standard terminals and a compact footprint delivers reliable, scalable protection for 50 A circuits, enabling easy integration into automation cabinets while supporting improved maintenance intervals and predictable performance for the broader electrical infrastructure.
Product Information
Extended Description
FAZ-Z50/4 Eaton: Eaton FAZ supplementary protector,UL 1077 Industrial miniature circuit breaker - supplementary protector,50 A,15 kAIC,Four-pole,2-3X /n,Standard terminals,Z Curve
Product Name
Eaton FAZ supplementary protector
Catalog Number
FAZ-Z50/4
EAN
4015082791209
Product Length/Depth
3 in
Product Height
3 in
Product Width
3 in
Product Weight
1 lb
Warranty
1 year
Certifications
UL 1077 CSA Std. C22.2 No.235 IEC 60947-2
Catalog Notes
Very low instantaneous setting to provide tighter protection for loads more sensitive to overcurrents.
Number of poles
Four-pole
Terminals
Standard
Amperage Rating
50 A
Trip Type
2-3X /n
