Eaton FAZ-Z6/3 supplementary protector - UL 1077
Part Number: FAZ-Z6/3
Quick Summary
FAZ-Z6/3 supplementary protector provides compact overcurrent protection for industrial control circuits and panel assemblies. Engineers often struggle with nuisance trips and tight protection settings that complicate panel design and maintenance. This device carries CSA Std. C22.2 No.235, UL 1077, and IEC 60947-2 certifications, ensuring compliance across North American and international standards. With a 6 A rating and a 2-3X instantaneous trip characteristic, it delivers reliable protection without sacrificing accessibility, while standard terminals simplify installation and wire management in existing assemblies. For OEMs and service teams, this translates to faster commissioning, reduced downtime, and a robust, space-efficient protection solution that fits into tight electrical layouts.
Product Information
Extended Description
FAZ-Z6/3 Eaton: Eaton FAZ supplementary protector,UL 1077 Industrial miniature circuit breaker - supplementary protector,6 A,15 kAIC,Three-pole,2-3X /n,Standard terminals,Z Curve
Product Name
Eaton FAZ supplementary protector
Catalog Number
FAZ-Z6/3
EAN
4015082789244
Product Length/Depth
3.5 in
Product Height
3 in
Product Width
2.25 in
Product Weight
0.7 lb
Warranty
1 year
Certifications
CSA Std. C22.2 No.235 UL 1077 IEC 60947-2
Catalog Notes
Very low instantaneous setting to provide tighter protection for loads more sensitive to overcurrents.
Number of poles
Three-pole
Terminals
Standard
Amperage Rating
6 A
Trip Type
2-3X /n
Feature → Business Impact → Application: The FAZ-Z6/3 provides 6 A rated protection, delivering precise overload control for sensitive loads, reducing nuisance tripping and extending equipment life in control cabinets and automation panels. This translates to lower maintenance costs and improved uptime for manufacturing lines and process control systems, especially where tight current limits are critical. Feature → Business Impact → Application: Three-pole design ensures balanced protection across all phases in three-phase systems, maintaining circuit integrity in motor drives and machine controls while simplifying wiring in compact control enclosures. Feature → Business Impact → Application: Very low instantaneous setting tightens protection for sensitive loads, minimizing damage from brief fault currents and reducing repair costs in robotics, CNC machines, and programmable logic controller (PLC) circuits. Feature → Business Impact → Application: Standard terminals enable quick scoping and straightforward replacement in legacy panels, reducing retrofit time and enabling seamless upgrades in existing installations. Feature → Business Impact → Application: CSA, UL 1077, and IEC 60947-2 certifications provide regulatory confidence for compliance-driven projects and OEMs, facilitating procurement and system approvals. Feature → Business Impact → Application: Compact form factor with reliable performance supports space-constrained installations in panelboards and automation enclosures, lowering cabinet footprint and simplifying wiring harness routing.
Get a Quick Quote for a Eaton FAZ-Z6/3
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton FAZ-Z6/3?
Enquire Now
FAQs
The FAZ-Z6/3 is designed for three-phase control circuits in industrial panels and automation enclosures. It uses standard terminals for easy integration into existing wiring schemes and supports IEC 60947-2 and UL 1077 compliant applications, making it suitable for retrofit projects and new panel builds alike.
Key specs include a 6 A nominal current rating, 2-3X instantaneous trip characteristic, and a fault current rating of up to 15 kAIC. It is a three-pole device with standard terminals, and it carries CSA, UL 1077, and IEC 60947-2 certifications for broad regulatory acceptance.
Yes. The 6 A rating with a very low instantaneous setting provides tight protection for sensitive loads, including motor control circuits and automation panels, while minimizing nuisance trips. Its three-pole design helps balance protection across all phases in motor and drive applications.
FAZ-Z6/3 is certified under UL 1077, CSA Std C22.2 No.235, and IEC 60947-2. These certifications validate safe, code-compliant operation across North America and international markets, facilitating procurement, installation approvals, and long-term reliability in industrial environments.
The device’s standard terminals simplify mounting and wiring, reducing installation time and potential wiring errors. Its compact three-pole design fits into tight panel spaces, enabling easier maintenance access and faster replacement without extensive rewiring, which supports lower total cost of ownership.
