Eaton FAZ-Z8/3 Supplementary Protector UL 1077
Part Number: FAZ-Z8/3
Quick Summary
The Eaton FAZ-Z8/3 Supplementary Protector provides targeted overcurrent protection for sensitive loads in control panels. Engineers frequently contend with nuisance trips and insufficient protection for delicate automation electronics. UL 1077, IEC 60947-2, and CSA C22.2 No.235 compliance ensure safe, code‑conforming protection in industrial environments. Its compact three‑pole design with standard terminals enables quick installation and reliable protection, translating into reduced downtime and lower maintenance costs for machine builders and panel shops.
Product Information
Extended Description
FAZ-Z8/3 Eaton: Eaton FAZ supplementary protector,UL 1077 Industrial miniature circuit breaker - supplementary protector,8 A,15 kAIC,Three-pole,2-3X /n,Standard terminals,Z Curve
Product Name
Eaton FAZ supplementary protector
Catalog Number
FAZ-Z8/3
EAN
4015082789251
Product Length/Depth
3 in
Product Height
3 in
Product Width
3 in
Product Weight
1 lb
Warranty
1 year
Certifications
UL 1077 IEC 60947-2 CSA Std. C22.2 No.235
Catalog Notes
Very low instantaneous setting to provide tighter protection for loads more sensitive to overcurrents.
Number of poles
Three-pole
Terminals
Standard
Amperage Rating
3 A
Trip Type
2-3X /n
Feature: Three-pole design with standard terminals. Business impact: Ensures synchronized protection across all phases and simplifies wiring, reducing commissioning time and wiring errors. Application: Control panels in industrial automation, machine builds, and retrofit projects. The result is faster, more reliable startups and easier expansion or modification of existing systems. Feature: Very low instantaneous setting to tighten protection for sensitive loads. Business impact: Minimizes nuisance trips on PLCs, sensors, and drives while preserving essential protection. Application: Drives and automation sensors in packaging, material handling, and process lines. Outcome: improved uptime and reduced unscheduled maintenance. Feature: 3 A rating with 15 kAIC interrupting capacity. Business impact: Safe interruption for small circuits while safeguarding equipment and personnel. Application: Small control circuits feeding sensors and logic modules, where precise protection matters. Outcome: enhanced safety margins without oversized breakers. Feature: Compact 3 in x 3 in x 3 in footprint and 1 lb weight with standard terminals. Business impact: Space‑saving design that simplifies panel layout and speeds installation. Application: Enclosed control panels and compact automation cabinets. Outcome: more efficient layouts and cost savings on enclosure real estate. Feature: 1 year warranty and multi‑certification footprint (UL 1077, IEC 60947-2, CSA). Business impact: Reduced lifecycle risk and compliance confidence for industrial builds. Application: New equipment deployments and refurbishments across regulated sectors. Outcome: lower total cost of ownership and clearer procurement alignment.
Get a Quick Quote for a Eaton FAZ-Z8/3
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton FAZ-Z8/3?
Enquire Now
FAQs
Install the FAZ-Z8/3 using the standard terminals across all three poles, ensuring equal torque on each terminal to prevent hotspots. Verify the mounting orientation fits within the panel space, align with existing conductor routing, and follow the 3 A current rating to select appropriate conductors and protection settings. This streamlined wiring reduces commissioning time and improves reliability in automation panels.
The FAZ-Z8/3 carries UL 1077, IEC 60947-2, and CSA C22.2 No.235 certifications. These mark compliance for industrial protective devices, ensuring safe operation, electrical interoperability, and regulatory alignment in North American and international markets. For engineers, this simplifies audits, procurement, and installation in regulated environments.
Yes. Its 3 A rating with a very low instantaneous setting provides tighter protection for sensitive automation loads such as PLCs, sensors, and drives. The three-pole design ensures balanced protection across phases, while the 15 kAIC interrupting capacity guards against higher fault currents common in automated systems.
The FAZ-Z8/3 employs a 2-3X /n trip characteristic, which offers a controlled instantaneous response tailored for sensitive loads. This minimizes nuisance trips during transient faults while delivering fast protection during sustained overcurrents. In practice, this translates to improved uptime for control panels and reduced wear on equipment from improper tripping.
With a 1 year warranty and standard terminals, the FAZ-Z8/3 reduces maintenance risk and simplifies replacement. Its compact 3x3x3 inch footprint aids panel density, lowering enclosure costs. The combination of tighter protection for delicate loads and proven certifications also lowers downtime costs and supports long-term return on investment in industrial automation projects.
