Eaton FDD1 Condulet FD device box - NEC/CEC (Industrial)
Part Number: FDD1
Quick Summary
Eaton FDD1 Condulet FD device box provides a rugged enclosure for terminating field wiring in harsh industrial settings. When space is tight and wiring must meet exacting codes, a deep, single-gang FD box reduces installation bottlenecks and risk. This model carries NEC/CEC compliance and is suitable for ordinary or non-hazardous locations, with Canadian certification documentation available. The FDD1's Feraloy iron alloy construction and 1/2" trade size align with standard conduit fittings, delivering long-term durability. By combining a compact footprint with robust materials, it supports safer, faster panel wiring and lower lifecycle costs. Collaborating with Eaton’s Crouse-Hinds family ensures consistent mounting patterns and cover compatibility for retrofit projects and new installations alike.
Product Information
Extended Description
FDD1 Eaton: Eaton Crouse-Hinds series Condulet FD device box, Deep, Feraloy iron alloy, Single-gang, D shape, 1/2"
Product Name
Eaton Crouse-Hinds series Condulet FD device box
Catalog Number
FDD1
UPC
782274399706
Product Length/Depth
5.16 in
Product Height
2.75 in
Product Width
2.69 in
Product Weight
2.95 lb
Area classification
Ordinary/Non-Hazardous Locations
Standards type
NEC/CEC
Depth
Deep
Number of gangs
1
Shape
D
Trade size
1/2"
Material
Feraloy iron alloy
Crouse-Hinds series FS, FD, Single, Multi, Blank Device Boxes and Covers catalog page
FS and FD Device Boxes and Covers Canadian certification
FS and FD Device Boxes and Covers Canadian certification
FS and FD Device Boxes and Covers Canadian certification
Eaton Specification Sheet - FDD1
Industrial Fittings Bend Radius and Cubic Capacity Chart
Feature deep single-gang FD device box design translates to increased wiring space and easier conduit routing, delivering measurable installation time savings and reduced field errors. The business impact is improved panel density and faster commissioning in control rooms and electrical rooms, with applications across manufacturing lines and process plants. Feature Feraloy iron alloy material provides superior corrosion resistance in harsh environments, decreasing maintenance cycles and extending service life—ideal for outdoor equipment and damp indoor locations. The business impact is lower total cost of ownership and fewer part replacements over the life of the system, with applications in water treatment, mining, and heavy industry. Feature 5.16 in length, 2.75 in height, 2.69 in width, and 2.95 lb weight offer predictable space planning and transportation logistics, improving procurement accuracy and on-site handling. The business impact is streamlined layout planning and safer, code-compliant installations across facilities. Feature NEC/CEC compliance and ordinary/non-hazardous area suitability reduce inspection risk and accelerate approvals, with clear applicability in US and Canadian projects. The business impact is faster project delivery and reduced audit findings, supported by catalog compatibility with FS/FD series device boxes for standardized wiring solutions. Feature 1/2" trade size and D-shaped footprint ensure compatibility with standard conduits and covers, delivering an install-ready enclosure that minimizes custom fabrication. The business impact is repeatable installs and lower training requirements for maintenance teams. Applications span panel wiring, junctions, and enclosure upgrades in industrial automation environments, with long-term cost savings from standardized Eaton components. Feature Pre-configured with Crouse-Hinds branding and a robust supply chain, supporting quick replacements and scalable installations for growing facilities.
Get a Quick Quote for a Eaton FDD1
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton FDD1?
Enquire Now
FAQs
The FDD1 is designed as a deep, single-gang Condulet FD device box with a 1/2" trade size, allowing straightforward entry for standard conduit fittings. Its D-shaped footprint and compact dimensions (5.16 in x 2.75 in x 2.69 in) enable efficient routing in tight control panels and junction boxes, while the Feraloy iron alloy shell provides robust protection against typical industrial conditions.
The FDD1 is NEC/CEC compliant and rated for Ordinary/Non-Hazardous Locations, ensuring code-conformant installation in US and Canadian facilities. Documentation resources and Canadian certification references are available, and the design aligns with FS/FD family practices to support reliable, compliant wiring installations.
The device box is specified for Ordinary/Non-Hazardous Locations, making it suitable for indoor use or sheltered outdoor environments but not for hazardous locations. For outdoor or harsh environments, consider enclosure strategies that provide additional ingress protection and enclosure ratings aligned with project requirements.
The FDD1 measures 5.16 inches in length, 2.75 inches in height, and 2.69 inches in width, with a weight of 2.95 pounds. These precise dimensions aid in enclosure planning, space management, and compatibility checks with existing backboxes and covers in Crouse-Hinds catalog configurations.
Choosing the FDD1 delivers code-compliant, durable housing with corrosion resistance from Feraloy iron alloy, reducing maintenance and replacement costs. Its standardized 1/2" trade size and compatibility with Eaton’s Condulet family streamline procurement, installation, and future upgrades, supporting faster project delivery and lower total cost of ownership in industrial automation environments.
