Eaton FG3050 Engine Generator MCB - UL Listed
Part Number: FG3050
Quick Summary
The Eaton FG3050 Engine Generator MCB provides protection for engine-driven power systems in industrial applications. Engine rooms and generator panels often suffer nuisance trips during starts; this device minimizes interruptions with fixed trip curves. It carries UL Listed and CSA Certified ratings, plus IEC compatibility, ensuring compliance across North American and international installations. Ideal for engine generator protection and industrial control panels, it supports reliable uptime and simplified maintenance. The design suits 60 Hz networks and 600 Vac line conditions, with line/load terminals for straightforward installation. Choosing FG3050 aligns with Eaton's engineering-grade protection philosophy and a robust warranty. This makes it a practical choice for OEMs and service teams seeking durable, code-compliant protection.
Product Information
Extended Description
FG3050 Eaton: Eaton Series C complete EG molded case circuit breaker, F-frame, FG, Fixed thermal and magnetic trips, Three-pole, 50A, 600 Vac, 18 kAIC at 240 Vac, 14 kAIC at 480 Vac, Line/load, Engine generator, Reverse, 60 Hz, Fixed
Product Name
Eaton complete engine generator molded case circuit breaker
Catalog Number
FG3050
UPC
786679269640
Product Length/Depth
7 in
Product Height
6 in
Product Width
5 in
Product Weight
4 lb
Warranty
Eaton Selling Policy 25-000, one (1) year from the date of installation of the Product or eighteen (18) months from the date of shipment of the Product, whichever occurs first.
Certifications
CSA Std. C22.2 No. 5 UL 489 IEC 947-2 IEC Rated UL Listed CSA Certified
Amperage Rating
50 A
Voltage rating
600 Vac
Trip Type
T186
Circuit breaker type
FG
Circuit breaker frame type
Complete breaker
Terminals
Line and load
Frame
F
Frequency rating
60 Hz
Class
Engine generator
Pickup
Fixed
Interrupt rating
14 kAIC at 480 Vac 18 kAIC at 240 Vac
Generator rating
18 kVA/14 kW at 240 Vac, 36 kVA/29 kW at 480 Vac, 45 kVA/36 kW at 600 Vac
Number of poles
Three-pole
Functions
Reverse
Engine generator circuit breakers catalog
Circuit Breakers Explained
Eaton Specification Sheet - FG3050
Selling Policy 25-000 - Distribution and Control Products and Services
50 A amperage rating with 600 Vac capability and a three-pole FG frame delivers targeted protection for engine-driven power systems in industrial facilities. Business impact: guards critical generator circuits against overloads while maintaining smooth operation during start-up transients, enabling safer panel installations and reduced downtime. Application: suits engine generator sets in manufacturing floors, data centers, and remote facilities, where reliability and predictable protection are essential. The fixed pickup and T186 trip type provide consistent response, minimizing nuisance trips in dynamic loading conditions. Application-specific advantage: engineers can rely on a known protection profile without recalibration after routine maintenance. The interrupt rating of 18 kAIC at 240 Vac and 14 kAIC at 480 Vac supports high fault current environments common in industrial generators, reducing equipment exposure to damaging faults. For integration, line/load terminals simplify wiring and field replacement, supporting quick swap-outs during maintenance windows. Certifications and standards—UL Listed, CSA Certified, IEC Rated—ensure compliance for global projects and OEM collaborations, reducing qualification steps. Weight and form factor (4 lb, compact F-frame) enable straightforward installation in control panels or generator enclosures. Warranty details follow Eaton policy, providing coverage through installation or shipment milestones. In practice, engineers experience improved maintenance cycles and lower total cost of ownership when pairing FG3050 with compatible engine-generator configurations under 60 Hz networks.
Get a Quick Quote for a Eaton FG3050
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton FG3050?
Enquire Now
FAQs
FG3050 is a three-pole molded case circuit breaker designed for engine generator control panels and industrial switchgear. It uses line/load terminals for straightforward wiring, fits standard 60 Hz 600 Vac systems, and aligns with F-frame enclosures. Its fixed pickup and T186 trip profile simplify installation in OEM generator packages and retrofit projects.
The FG3050 provides 18 kAIC at 240 Vac and 14 kAIC at 480 Vac. This performance supports high fault current environments typical of engine-generator applications, reducing the risk of cascading faults and protecting upstream equipment during generator start-ups or load changes.
Yes. FG3050 is specifically designed for engine-driven power systems, offering a 50 A rating, 600 Vac operation, and a three-pole configuration. It protects engine-generator circuits in manufacturing and processing facilities, ensuring reliable protection while meeting industry standards and integration with standard generator controls.
FG3050 is UL Listed, CSA Certified, and IEC Rated, with compatibility to IEC standards for broader international deployment. This combination supports regulatory compliance in North American facilities and global projects, simplifying supplier qualification and reducing certification cycles.
Eaton provides a warranty per Selling Policy 25-000, typically one year from installation or eighteen months from shipment, whichever occurs first. The rugged fixed pickup and stable trip characteristics reduce nuisance trips, improving uptime and lowering maintenance costs over the life of engine-generator protection.
