Eaton FG3070 Engine Generator MCCB - UL Listed
Part Number: FG3070
Quick Summary
Eaton FG3070 engine generator MCCB protects generator electrical systems with reliable molded case protection for engine-driven power units. That protection gap often leads to nuisance trips and unplanned downtime during startup or load changes. UL Listed, CSA Certified, and IEC rated for engine-generator service ensure compliance across industrial facilities and service fleets. Engineered for 60 Hz operation at 70 A and 600 Vac, the FG3070 simplifies installation, streamlines maintenance, and supports reliable performance in critical power systems. Its fixed thermal and magnetic trips deliver fast protection with predictable trips under fault or overload, reducing the risk of equipment damage.
Product Information
Extended Description
FG3070 Eaton: Eaton Series C complete EG molded case circuit breaker, F-frame, FG, Fixed thermal and magnetic trips, Three-pole, 70A, 600 Vac, 18 kAIC at 240 Vac, 14 kAIC at 480 Vac, Line/load, Engine generator, Reverse, 60 Hz, Fixed
Product Name
Eaton complete engine generator molded case circuit breaker
Catalog Number
FG3070
UPC
786679269688
Product Length/Depth
7 in
Product Height
6 in
Product Width
5 in
Product Weight
4 lb
Warranty
Eaton Selling Policy 25-000, one (1) year from the date of installation of the Product or eighteen (18) months from the date of shipment of the Product, whichever occurs first.
Certifications
UL Listed IEC 947-2 UL 489 CSA Certified IEC Rated CSA Std. C22.2 No. 5
Amperage Rating
70A
Voltage rating
600 Vac
Trip Type
T186
Circuit breaker type
FG
Circuit breaker frame type
Complete breaker
Terminals
Line and load
Frame
F
Frequency rating
60 Hz
Class
Engine generator
Pickup
Fixed
Interrupt rating
14 kAIC at 480 Vac 18 kAIC at 240 Vac
Generator rating
25 kVA/20 kW at 240 Vac, 51 kVA/40 kW at 480 Vac, 63 kVA/51 kW at 600 Vac
Number of poles
Three-pole
Functions
Reverse
Engine generator circuit breakers catalog
Circuit Breakers Explained
Eaton Specification Sheet - FG3070
Three-pole FG frame molded case circuit breaker with fixed thermal and magnetic trips delivers 70A protection for engine-driven power units, rated for 600 Vac with interrupt capabilities of 18 kAIC at 240 Vac and 14 kAIC at 480 Vac. This combination provides reliable short-circuit and overload defense, minimizing engine-generator downtime and protecting downstream equipment in demanding 60 Hz environments. The FG3070 is designed for engine-generator panels with line/load terminals, enabling straightforward wiring and fast field installation, which reduces commissioning time and potential wiring errors. Generator ratings scale across voltages: 25 kVA/20 kW at 240 Vac, 51 kVA/40 kW at 480 Vac, and 63 kVA/51 kW at 600 Vac, ensuring correct protection across common generator sizes encountered in industrial facilities. Its compact footprint (7 in L x 5 in W x 6 in H) and modest weight of 4 lb simplify panel integration and retrofit projects. Certifications include UL Listed, UL 489 compatibility, IEC Rated, and CSA Certified, providing confidence for compliance audits and cross-border installations. The device supports engine-generator service with a fixed pickup (T186), offering predictable protection during startup and load transients while maintaining ease of procurement through standardized frame and terminals. Warranty coverage (one year from installation or 18 months from shipment) reduces risk for project owners and service teams, helping protect capital investments during deployment.
Get a Quick Quote for a Eaton FG3070
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton FG3070?
Enquire Now
FAQs
FG3070 is a three-pole unit with line/load terminals and a compact 7 in L x 5 in W x 6 in H footprint, weighing 4 lb. It mounts in standard engine-generator control panels and accepts straightforward wiring from generator outputs, simplifying retrofits and new builds in 60 Hz installations.
Amperage rating: 70A; Voltage rating: 600 Vac; Trip type: T186; Generator ratings: 25 kVA/20 kW at 240 Vac, 51 kVA/40 kW at 480 Vac, 63 kVA/51 kW at 600 Vac; Interrupt rating: 18 kAIC at 240 Vac, 14 kAIC at 480 Vac; Frame: FG; Poles: Three-pole; Frequency: 60 Hz.
Yes. FG3070 is explicitly specified for 60 Hz service and engine-generator use, providing appropriate protection curves, fixed pickup, and compatibility with engine-driven power systems common in industrial facilities.
FG3070 is UL Listed and UL 489 compliant, IEC rated, and CSA Certified (CSA Std. C22.2 No. 5), ensuring cross-border safety and performance compliance for industrial and commercial applications.
Eaton provides a warranty per policy 25-000: one year from installation or eighteen months from shipment, whichever comes first, helping manage risk and service planning for engine-generator projects.
