Eaton FIG 2002 8 X 1 1/2SWY B/A PLN - UL Listed
Part Number: FIG 2002 8 X 1 1/2SWY B/A PLN
Quick Summary
FIG 2002 8 X 1 1/2SWY B/A PLN is a lateral sway brace attachment used for seismic pipe support systems. Engineers often struggle with compatibility and installation clarity when retrofitting seismic bracing in crowded mechanical spaces. UL Listed certification supports safety compliance, and Eaton provides Seismic Engineering Guidelines and Seismic Engineering Services to help with design and documentation. This solution aligns with Tolco B-Line assemblies, delivering reliable performance, straightforward installation, and long-term cost savings for industrial facilities and critical infrastructure projects.
Product Information
Extended Description
FIG 2002 8 X 1 1/2SWY B/A PLN Eaton: Eaton B-Line series TOLCO lateral sway brace attachment, Plain, Steel, Fig 2002, 8" pipe size with 1.5" brace pipe, Sway brace attachment
Product Name
Eaton B-Line series TOLCO lateral sway brace attachment
Catalog Number
FIG 2002 8 X 1 1/2SWY B/A PLN
UPC
782051721065
Product Length/Depth
0 in
Product Height
1.5 in
Product Width
0 in
Product Diameter
8 in
Product Weight
3.813 lb
Certifications
UL Listed
Finish
Plain
Material
Steel
Size
8 inch pipe size with 1.5 inch brace pipe
Model
Fig 2002
Type
Sway brace attachment
Seismic engineering services
Seismic engineering services
Seismic engineering guidelines
Seismic engineering guidelines
Eaton Specification Sheet - FIG 2002 8 X 1 1/2SWY B/A PLN
Feature: 8 inch pipe size with 1.5 inch brace pipe matches standard B-Line Tolco installations. Business Impact: Reduces field fabrication time and ensures a secure, code-compliant sway bracing connection. Application: Suitable for seismic bracing in electrical rooms and mechanical assemblies that use 8" pipe runs. Feature: Plain steel finish. Business Impact: Cost-effective material choice with straightforward painting or coating in-field, lowering total installed cost. Application: Ideal for high-volume installations in industrial facilities where cosmetic finish is less critical. Feature: UL Listed certification. Business Impact: Streamlines QA and meets regulatory requirements, reducing inspection risk and project delays. Application: Essential for electrical service installations and critical infrastructure projects requiring approved components. Feature: Sway brace attachment design (Fig 2002). Business Impact: Quick, tool-assisted installation with a secure clamp profile that minimizes service disruption. Application: Beneficial for retrofit projects and new builds in confined spaces. Feature: Compatibility with Eaton B-Line Tolco series. Business Impact: Simplifies procurement and spares planning by ensuring seamless integration with existing Tolco components. Application: Supports scalable seismic bracing strategies across facilities with standardized hardware.
