Eaton FNQ-R-1-1/8 Fuse - Class CC Time-delay, 200 kAIC
Part Number: FNQ-R-1-1/8
Quick Summary
The Eaton FNQ-R-1-1/8 fuse is a current-limiting solution designed for line protection in small control panels and industrial transformers. In practice, engineers struggle with nuisance trips during inrush or miscoordination between upstream and downstream devices; this fuse’s time-delay, dual-element construction helps tolerate brief surges while preserving critical protection. This device is CE marked and RoHS compliant, supporting regulatory compliance across global markets, and it carries a 600 V rating with a robust 200 kAIC interrupt rating. By pairing these specifications with a compact ferrule-end design, the FNQ-R supports easy installation, reliable operation in tight spaces, and reduced total cost of ownership for panel builders and OEMs.
Product Information
Extended Description
FNQ-R-1-1/8 Eaton: Eaton Bussmann Series Class CC fuse, FNQ, time-delay, dual-element current limiting fuse, 1.125 A, rejection style fuse, interrupting rating of 200kA at 600Vac
Product Name
Eaton Bussmann series FNQ-R fuse
Catalog Number
FNQ-R-1-1/8
UPC
051712497053
EAN
5027590449632
Product Length/Depth
0.41 in
Product Height
1.5 in
Product Width
0.41 in
Product Weight
0.15 lb
Warranty
Not Applicable
Compliances
CE Marked RoHS Compliant
Type
Current-limiting high inrush time-delay fuse
Special features
Rejection style
Application
Line protection, small control transformers, industrial control, branch circuits
Amperage Rating
1.125A
Class
Class CC
Interrupt rating
200 kAIC
Fuse indicator
Non-indicating
Connection
Ferrule end x ferrule end
Response time
12 sec at 200%
Material
Melamine tube
Packaging type
Standard
Voltage rating
600 V
Bussmann Full Line Catalog
Bussmann Full Line Catalog
RoHS Search Tool
Bussmann series Fuseology
Bussmann series FNQ-R Class CC Fuse Data Sheet No. 1014
Feature → Business Impact → Application: The FNQ-R-1-1/8 uses a dual-element, current-limiting time-delay design that tolerates inrush surges without sacrificing fast fault clearing, improving equipment uptime and reducing nuisance trips in control panels and small transformers. This translates to measurable downtime reductions and smoother startup sequences in industrial automation workflows, particularly where transformer inrush is common. Feature → Business Impact → Application: With an interrupt rating of 200 kAIC at 600 V, this fuse delivers high fault-current protection, safeguarding downstream devices and wiring from catastrophic damage while maintaining selectivity in mixed circuits found in branch protections and industrial control circuits. Feature → Business Impact → Application: Ferrule-end x ferrule-end connections simplify installation in standard Bussmann FNQ-R assemblies, enabling quick panel integration, reliable mating with existing conduit fittings, and improved vibration resistance in harsh factory environments. Feature → Business Impact → Application: The rejection-style format minimizes the risk of incorrect fuse installation in multi-fuse panels, reducing maintenance errors and ensuring proper protection coordination across feeders and control circuits. Feature → Business Impact → Application: RoHS compliant and CE marked, the FNQ-R aligns with environmental and safety standards while supporting global procurement strategies and regulatory compliance for multinational OEMs. Feature → Business Impact → Application: With a 1.125 A rating and a 12-second response at 200% load, designers can optimize protection without derating nearby components, enabling smaller controllers and compact power supplies in line protection and branch circuit applications.
