Eaton FNQ-R-5-6/10 Fuse Time-Delay - Class CC, 200 kAIC
Part Number: FNQ-R-5-6/10
Quick Summary
The Eaton FNQ-R-5-6/10 fuse provides time-delay current-limiting protection for industrial control circuits. Engineers often struggle with nuisance trips during motor starts and transformer inrush, leading to costly downtime. CE marking and RoHS compliance help meet global safety and environmental requirements, while a 600 V rating supports industrial use. This fuse pairs with Bussmann series data and standard ferrule-end connections for straightforward installation and reliable protection across control panels. In practice, the FNQ-R-5-6/10 reduces nuisance trips, improves uptime, and simplifies spare-part management across scalable automation setups. Its ferrule-end connections and compact 1.5 inch length support fast retrofit, while the 12 second response at 200% delivers predictable protection.
Product Information
Extended Description
FNQ-R-5-6/10 Eaton: Eaton Bussmann Series Class CC fuse, FNQ, time-delay, dual-element current limiting fuse, 5.6 A, rejection style fuse, interrupting rating of 200kA at 600Vac
Product Name
Eaton Bussmann series FNQ-R fuse
Catalog Number
FNQ-R-5-6/10
UPC
051712582438
Product Length/Depth
1.5 in
Product Height
0.41 in
Product Width
0.41 in
Product Weight
0.15 lb
Warranty
Not Applicable
Compliances
CE Marked RoHS Compliant
Type
Current-limiting high inrush time-delay fuse
Special features
Rejection style
Application
Line protection, small control transformers, industrial control, branch circuits
Amperage Rating
5.60A
Class
Class CC
Interrupt rating
200 kAIC
Fuse indicator
Non-indicating
Connection
Ferrule end x ferrule end
Response time
12 sec at 200%
Material
Melamine tube
Packaging type
Standard
Voltage rating
600 V
Low Voltage Branch Circuit Fuse Chapter
Low Voltage Branch Circuit Fuse Chapter
RoHS Search Tool
Bussmann series Fuseology
Bussmann series FNQ-R Class CC Fuse Data Sheet No. 1014
Feature → Business Impact → Application: The FNQ-R-5-6/10 is a current-limiting time-delay fuse that tolerates inrush while protecting downstream circuitry, reducing unplanned downtime in manufacturing lines. This translates to improved line reliability and lower maintenance costs for OEMs and integrators working with small control transformers and branch circuits. Feature → Business Impact → Application: With a 5.6 A rating and 200 kAIC interrupt capability, it safeguards sensitive loads without wide-scale system disruption, enabling compact panel designs in machine builders and panel shops. Feature → Business Impact → Application: Ferrule-end connections and a 1.5 in length enable quick, plug-and-play installs in standard Bussmann-series fuse blocks, minimizing commissioning time in control cabinets. Feature → Business Impact → Application: The CE RoHS compliance ensures regulatory alignment for global deployments, simplifying sourcing and procurement for multinational projects. Feature → Business Impact → Application: Class CC current-limiting design reduces energy waste and supports compliance with electrical protection standards in line protection, small transformers, and industrial control circuits.
