Eaton FRN-R-40 Fuse - RK5 Class, 40A, 200 kAIC
Part Number: FRN-R-40
Quick Summary
The Eaton FRN-R-40 fuse provides time-delay overload protection for control circuits in industrial equipment. In many plants, nuisance trips during startup surges disrupt production and complicate maintenance; a robust fuse like FRN-R-40 reduces downtime and extends equipment life. CE marking confirms European safety compliance for this RK5-class fuse, and its dual-element, current-limiting design offers reliable operation across dynamic loads. This solution also aligns with industry expectations for finger-safe protection and easy field replacement, while supporting standard ferrule-end connections. For procurement, the 40 A rating delivers a balance of protection and cost, with a well-documented data sheet and compatibility with Bussmann-series catalogs.
Product Information
Extended Description
FRN-R-40 Eaton: Eaton Bussmann Series Class RK5 fuse, FRN-R, time-delay, dual-element, current limiting fuse, 40 A, non-indicating fuse, interrupting rating of 200 kA at 250 Vac and 20 kA at 125 Vdc
Product Name
Eaton Bussmann series FRN-R fuse
Catalog Number
FRN-R-40
UPC
051712101783
Product Length/Depth
3 in
Product Height
0.81 in
Product Width
0.81 in
Product Weight
0.11 lb
Warranty
Not Applicable
Compliances
CE Marked
Amperage Rating
40 A
Interrupt rating
20 kAIC at 125 Vdc 200 kAIC at 250 Vac
Response time
10 sec at 500%
Voltage rating
250 Vac, 125 Vdc
Number of elements
Dual
Packaging type
Standard
Class
Class RK5
Connection
Ferrule end x ferrule end
Fuse indicator
Non-indicating
Special features
Finger safe
Bussmann Full Line Catalog
Bussmann Full Line Catalog
RoHS Search Tool
Bussmann series Fuseology
Bussmann series Fusetron FRN-R RK5 fuse data sheet for up to 60 amps No. 1019
Feature: Time-delay, dual-element, current-limiting protection. Business Impact: Enables selective coordination and reduces nuisance trips during normal startup surges, improving equipment uptime. Application: Motor control centers, drives, and power distribution panels. Feature: 40 A rating with high interrupt capability. Business Impact: Handles heavier fault currents without premature nuisance trips, safeguarding downstream components. Application: Branch circuits feeding motors and large loads in manufacturing lines. Feature: Dual-element design with 200 kAIC at 250 VAC and 20 kAIC at 125 VDC. Business Impact: Robust fault protection across AC and DC applications, minimizing damage and downtime. Application: Mixed-voltage control panels and feeder circuits. Feature: Ferrule-end connections and finger-safe construction. Business Impact: Simplifies installation and replacement in field-mounted assemblies while enhancing operator safety. Application: Retrofit projects and OEM control enclosures. Feature: Class RK5, non-indicating, standard packaging. Business Impact: Fast, reliable stocking and compatibility with RK5-fuse holders and Bussmann catalogs, reducing procurement complexity. Application: Mass deployments across plant-wide protection schemes.
Get a Quick Quote for a Eaton FRN-R-40
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton FRN-R-40?
Enquire Now
FAQs
FRN-R-40 uses ferrule-end connections and follows the RK5 format, allowing seamless installation in standard RK5 fuse holders. The ferrule-end design supports quick, reliable replacement in control panels and enclosures, with a 3 inch overall length and a compact footprint that fits typical tray and panel layouts.
The fuse is rated at 40 A with interrupt ratings of 200 kAIC at 250 VAC and 20 kAIC at 125 VDC. It is a time-delay, dual-element, current-limiting device with a 10 second response at 500% overload, making it suitable for motors and circuits with short surges while protecting downstream components.
Yes. The time-delay, dual-element RK5 fuse provides reliable protection during startup surges while avoiding nuisance trips on normal inrush. Its 40 A rating and high interrupt capacity support motor circuits and drives in industrial panels, reducing downtime and extending equipment life.
The product is CE marked, indicating compliance with European safety standards. Other certifications are not listed in the provided data; for additional regulatory requirements, consult regional safety and compliance guidelines and the Bussmann catalogs.
Finger-safe construction, non-indicating operation, and ferrule-end connections simplify maintenance and field replacement, reducing service time. The robust interrupt ratings and time-delay performance improve uptime, while compatibility with standard RK5 holders and Bussmann catalogs streamlines procurement and inventory management.
