Eaton FT440 Marine Interior Lighting - NEC/CEC Standards
Part Number: FT440
Quick Summary
FT440 is a marine interior lighting fixture delivering 4-lamp, 120V illumination for vessel interiors. In harsh shipboard environments, maintenance downtime and regulatory compliance gaps can drive costly outages. The FT440 adheres to NEC/CEC standards and is rated for Ordinary/Non-Hazardous Locations, featuring a copper-free aluminum housing and an acrylic lens for durability in corrosive atmospheres. This recessed ceiling design simplifies installation in standard 2x4 ft plenum spaces while maintaining a clean, ship-grade appearance. With 34W consumption across four lamps at 120 VAC and 60 Hz, operators gain reliable brightness without excessive energy use. The unit's robust build supports longer service life, predictable spare-part planning, and lower total cost of ownership for fleets.
Product Information
Extended Description
FT440 Eaton: Eaton Crouse-Hinds series Pauluhn Meridian FT marine interior, 60 Hz, 2 ft x 4 ft, Acrylic lens, T12ES, Copper-free aluminum, Recessed ceiling mount, 4-lamp, 120 Vac, 34W
Product Name
Eaton Crouse-Hinds series Pauluhn Meridian FT marine interior
Catalog Number
FT440
UPC
662276398122
Product Length/Depth
48.13 in
Product Height
5.19 in
Product Width
23.88 in
Product Weight
23 lb
Area classification
Ordinary/Non-Hazardous Locations
Standards type
NEC/CEC
Lamp length
2 x 4 ft
Light type
T12ES
Number of lamps
4-lamp
Wattage
34W
Voltage rating
120 Vac
Frequency rating
60 Hz
Mounting Method
Recessed ceiling
Material
Copper-free aluminum
Lens material
Acrylic
Eaton Crouse-Hinds FT440 3D drawing
Crouse-Hinds series Pauluhn FT Marine Interior Low Profile Surface Lights catalog page
IF LBL1486 - FT, CE Fluorescent Luminaires
IF LBL1486 - FT, CE Fluorescent Luminaires
Eaton Specification Sheet - FT440
Feature 1: 2 x 4 ft, 4-lamp T12ES fluorescent luminaire provides broad, even illumination across workspaces. Business impact: improved visibility reduces errors and enhances safety in busy marine deck and machinery areas. Application: shipboard corridors, galleys, and equipment bays where uniform light is critical. Feature 2: Copper-free aluminum housing delivers superior corrosion resistance in salt air environments, decreasing maintenance cycles and replacement costs. Business impact: lower total cost of ownership and fewer downtime events. Application: exterior-facing interiors and engine rooms adjacent spaces where exposure to moisture is common. Feature 3: Acrylic lens offers durable impact resistance and easy cleaning, maintaining optical clarity over time. Business impact: consistent light levels and reduced cleaning labor. Application: crew quarters and maintenance zones with frequent access. Feature 4: Recessed ceiling mounting supports neat integration with standard 2x4 ft grid ceilings, enabling rapid installations and future retrofits. Business impact: reduced installation time and compatibility with existing shipboard infrastructure. Application: retrofit projects in aging fleets. Feature 5: Electrical specs of 120 VAC, 60 Hz and 34W total consumption enable reliable operation while moderating energy use. Business impact: energy efficiency supports fleet-wide sustainability goals and predictable operating costs. Application: general lighting for ordinary locations. Feature 6: NEC/CEC standards compliance and Ordinary/Non-Hazardous Locations rating provide regulatory alignment and safer operation. Business impact: streamlined approvals and improved risk management for marine vessels. Application: compliant lighting across engineering, cargo, and crew areas.
Get a Quick Quote for a Eaton FT440
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton FT440?
Enquire Now
FAQs
FT440 uses a recessed ceiling mount designed for standard 2x4 ft grid ceilings. The unit measures 48.13 in long by 23.88 in wide and 5.19 in high, with a weight of about 23 lb, making installation straightforward in typical shipboard ceiling applications. It supports 120 VAC, 60 Hz operation and uses a 4-lamp 2x4 ft configuration with an acrylic lens.
FT440 operates at 120 VAC and 60 Hz with a total wattage of 34 W across four lamps. This combination provides reliable illumination while minimizing energy consumption, contributing to lower operating costs on fleets and reduced thermal load in engine and machinery spaces.
Yes. FT440 is rated for Ordinary/Non-Hazardous Locations and complies with NEC/CEC standards. This makes it appropriate for general vessel interiors where standard lighting performance and regulatory alignment are required, without the need for specialized explosion-proof features.
FT440 aligns with NEC/CEC standards and is classified for Ordinary/Non-Hazardous Locations. These certifications support regulatory approval and safer operation in typical shipboard environments, improving procurement confidence and reducing compliance risks.
Copper-free aluminum construction provides improved corrosion resistance, reducing maintenance frequency in salt-air environments. The 34W, 2x4 ft 4-lamp configuration offers efficient lighting with long service life, enabling lower lifecycle costs, fewer replacements, and predictable uptime across fleets.
